Cardone 19-2709 Disc Brake Caliper - Front Left

Overview of Cardone Unloaded Caliper for Lexus LS430

The Cardone 19-2709 Unloaded Caliper is a remanufactured disc brake caliper designed specifically for the Lexus LS430. Engineered to meet OEM specifications, this gray oil emulsion finished caliper ensures reliable braking performance and durability.

• Remanufactured disc brake caliper with steel pistons
• Compatible with Lexus LS430 models
• Includes caliper and hardware kit; mounting bolts not included
• Bleeder and inlet port size: M10x1.0
• Finished with oil emulsion coating in gray for corrosion resistance
• Four steel pistons with 42.75 mm outer diameter

Cardone Unloaded Caliper Product Line Details

The Unloaded Caliper line from Cardone offers remanufactured brake calipers that come without brake pads installed, allowing for flexible installation with existing or aftermarket pads. This product line focuses on delivering reliable hydraulic brake components that meet or exceed OEM standards, providing a cost-effective solution for brake system repairs on vehicles like the Lexus LS430.

Product Features and Specifications

This Cardone 19-2709 caliper features a steel piston construction with four pistons, each measuring approximately 42.75 mm in diameter. The caliper is finished with an oil emulsion coating in gray, which helps protect against corrosion and wear. Both the bleeder port and inlet port are sized M10x1.0, ensuring compatibility with the brake hydraulic system of the Lexus LS430. The package includes the caliper and a hardware kit, though mounting bolts are not included.

Common Applications and Problem Resolution

• Replacement for worn or leaking brake calipers on Lexus LS430
• Addresses symptoms such as low brake pedal caused by air in the brake system
• Helps resolve uneven braking or vehicle pulling to one side during braking
• Eliminates brake squeal related to caliper issues
• Restores proper brake hydraulic function and pedal feel

Installation Notes and Tips

When installing the Cardone 19-2709 caliper, use the included hardware kit for secure mounting. Note that mounting bolts are not included and must be sourced separately if needed. It is recommended to use the brake fluid specified by the vehicle manufacturer, typically DOT 3 or DOT 4. Applying silicone grease on floating caliper mounting pins can help maintain smooth caliper movement. Always bleed the brake system thoroughly to remove air and ensure proper pedal feel.

Quality Assurance and Warranty

This remanufactured caliper undergoes rigorous testing to meet OEM performance standards. Cardone provides a limited warranty on this part, covering defects in materials and workmanship. Using this caliper helps maintain the safety and reliability of the Lexus LS430 braking system.
