Cardone 19-2945 Disc Brake Caliper - Rear Left

Overview of Cardone Unloaded Caliper 19-2945

The Cardone Unloaded Caliper 19-2945 is a remanufactured disc brake caliper designed for select Mercedes-Benz models including the C230, C240, SLK280, and SLK300. Engineered with a phenolic piston and an oil emulsion finish, this caliper offers reliable braking performance and corrosion resistance.

• Remanufactured disc brake caliper with phenolic pistons
• Compatible with Mercedes-Benz C230, C240, SLK280, SLK300
• Includes caliper and hardware kit; mounting bolts not included
• Bleeder port size: M8x1.25; inlet port size: M10x1.0
• Caliper color: gray with oil emulsion finish for durability
• Two 35.814 mm diameter phenolic pistons for effective braking
• Installation hardware included for ease of replacement

Cardone Unloaded Caliper Product Line Details

The Cardone Unloaded Caliper line provides remanufactured brake calipers that come without brake pads, allowing for flexibility in pad selection. This product line focuses on delivering reliable hydraulic brake components that meet or exceed original equipment specifications. The 19-2945 caliper is part of this line, offering a quality remanufactured option for Mercedes-Benz vehicles requiring disc brake caliper replacement.

Technical Description and Features

This Cardone 19-2945 caliper features two phenolic pistons measuring 35.814 mm in diameter, which help reduce heat transfer to the brake fluid, minimizing the risk of brake fade. The caliper’s gray oil emulsion finish provides corrosion resistance, extending the service life of the component. It includes a bleeder port sized M8x1.25 and an inlet port sized M10x1.0, compatible with the brake hydraulics system of the specified Mercedes-Benz models. The package contains the caliper and a hardware kit, though mounting bolts are not included. The use of silicone grease on floating caliper mounting pins is recommended for proper operation.

Applications and Problem Resolution

• Replacement for worn or leaking disc brake calipers on Mercedes-Benz C230, C240, SLK280, and SLK300
• Addresses symptoms such as low brake pedal height caused by air in the brake system
• Helps resolve uneven braking or vehicle pulling to one side during braking
• Eliminates brake squeal related to caliper issues
• Restores proper brake hydraulic function and pedal feel

Installation Notes and Tips

When installing the Cardone 19-2945 caliper, ensure the use of brake fluid recommended by the original equipment manufacturer, typically DOT 3 or DOT 4. Apply silicone grease to the floating caliper mounting pins to maintain smooth caliper movement. Although the hardware kit is included, mounting bolts must be sourced separately. Bleed the brake system thoroughly after installation to remove any air and restore proper pedal height.

Quality Assurance and Warranty

This remanufactured caliper undergoes rigorous testing to meet OEM standards for fit, form, and function. Cardone provides a limited warranty covering defects in materials and workmanship, ensuring dependable performance for your Mercedes-Benz braking system.
