Cardone 19-B2066 Disc Brake Caliper - Rear Right

Overview of Cardone Unloaded Caliper w/Bracket 19-B2066

The Cardone Unloaded Caliper w/Bracket 19-B2066 is a remanufactured disc brake caliper designed specifically for Subaru Forester and Impreza models. Engineered with a steel piston and finished with an oil emulsion coating, this caliper ensures reliable braking performance and corrosion resistance.

• Remanufactured disc brake caliper with bracket
• Compatible with Subaru Forester and Impreza
• Steel piston with 37.973 mm outer diameter
• Oil emulsion brake caliper finish in gray color
• Includes caliper, bracket, and hardware kit (mounting bolts not included)
• Bleeder port size: M7x1.0; inlet port size: M10x1.0
• Installation hardware included for ease of replacement

Product Line Details: Unloaded Caliper w/Bracket

The Cardone Unloaded Caliper w/Bracket product line offers remanufactured calipers that come complete with the mounting bracket and necessary hardware kit. This design simplifies installation by providing all essential components except mounting bolts, which must be reused or sourced separately. The unloaded configuration means the caliper does not include brake pads, allowing for flexibility in pad selection based on vehicle requirements.

Technical Description and Features

This Cardone 19-B2066 caliper features a single steel piston with a precise 37.973 mm outer diameter, providing consistent hydraulic pressure for effective braking. The gray oil emulsion finish protects against rust and wear, extending the caliper’s service life. The bleeder port (M7x1.0) and inlet port (M10x1.0) sizes conform to OEM specifications, ensuring compatibility with the Subaru brake system. The caliper uses silicone grease on floating caliper mounting pins to maintain smooth operation and reduce noise.

Common Applications and Problem Resolution

• Replacement for worn or leaking calipers on Subaru Forester and Impreza models
• Addresses symptoms such as low brake pedal caused by air in the brake system
• Helps resolve uneven braking or vehicle pulling to one side
• Eliminates brake squeal related to caliper hardware or mounting issues
• Restores proper hydraulic pressure and brake fluid flow

Installation Notes and Tips

Installation of the Cardone 19-B2066 caliper requires reusing existing mounting bolts, as they are not included. The package contains the caliper, bracket, and necessary hardware kit for mounting. It is recommended to use the brake fluid type specified by the vehicle manufacturer (DOT 3, DOT 4, or DOT 5) and to bleed the brake system thoroughly to remove air and ensure proper pedal feel. Applying silicone grease to the floating caliper mounting pins will help maintain smooth caliper movement and reduce noise.

Quality Assurance and Warranty

This remanufactured caliper undergoes rigorous testing to meet OEM standards for fit, form, and function. Cardone provides a warranty on this part to cover defects in materials and workmanship, offering assurance of its reliability and durability when installed on compatible Subaru Forester and Impreza vehicles.
