Cardone 19-B2590 Disc Brake Caliper - Front Left

Overview of Cardone Unloaded Caliper w/Bracket 19-B2590

The Cardone Unloaded Caliper w/Bracket 19-B2590 is a remanufactured disc brake caliper designed specifically for Volvo models including the S60, S80, V70, and XC70. Engineered with a steel piston and finished with an oil emulsion coating, this caliper ensures reliable braking performance and corrosion resistance.

• Remanufactured disc brake caliper with bracket
• Compatible with Volvo S60, S80, V70, and XC70
• Steel piston with 59.87 mm outer diameter
• Oil emulsion gray finish for durability
• Includes caliper, bracket, and hardware kit
• Bleeder and inlet port size: M10x1.0
• Installation hardware included; mounting bolts not included

Product Line Details: Unloaded Caliper w/Bracket

The Cardone Unloaded Caliper w/Bracket product line offers remanufactured calipers that come complete with the mounting bracket and necessary hardware kit. This design simplifies installation by providing all essential components except mounting bolts, which must be sourced separately. The unloaded configuration means brake pads are not included, allowing for customization or reuse of existing pads. This line is tailored for professional repair and maintenance of brake hydraulics on compatible vehicles.

Technical Description and Features

This Cardone 19-B2590 caliper features a single steel piston with a precise 59.8678 mm outer diameter, providing consistent clamping force on the brake rotor. The gray oil emulsion finish protects against rust and wear, extending the caliper’s service life. Both the bleeder and inlet ports use an M10x1.0 thread size, matching OEM specifications for easy integration. The caliper uses silicone grease on floating caliper mounting pins to ensure smooth operation and reduce noise. This remanufactured part meets OEM standards for fit and function on Volvo S60, S80, V70, and XC70 models.

Common Applications and Problem Resolution

• Replaces worn or leaking disc brake calipers on Volvo S60, S80, V70, and XC70
• Addresses symptoms of low brake pedal often caused by air in the brake system
• Helps resolve uneven braking or vehicle pulling to one side during braking
• Eliminates brake squeal related to caliper hardware or mounting issues
• Restores proper brake hydraulic function for improved safety and control

Installation Notes and Tips

Installation of the Cardone 19-B2590 caliper requires proper brake fluid as recommended by the vehicle manufacturer, typically DOT 3 or DOT 4. The included hardware kit facilitates mounting, but mounting bolts are not supplied and must be reused or replaced separately. Use silicone grease on floating caliper mounting pins to maintain smooth caliper movement and prevent noise. Bleed the brake system thoroughly after installation to remove air and ensure firm brake pedal feel.

Quality Assurance and Warranty

This remanufactured Cardone caliper undergoes rigorous testing to meet OEM specifications for durability and performance. While specific warranty details are not provided here, Cardone products typically include a limited warranty covering defects in materials and workmanship. Using this caliper helps maintain the integrity of the brake hydraulic system on Volvo S60, S80, V70, and XC70 vehicles.
