Cardone 19-B2775 Disc Brake Caliper - Front Left

Overview of Cardone Unloaded Caliper w/Bracket 19-B2775

The Cardone Unloaded Caliper w/Bracket 19-B2775 is a remanufactured disc brake caliper designed specifically for Lexus GS300, GS400, GS430, and SC430 models. Engineered to meet OEM specifications, this caliper ensures reliable braking performance and durability.

• Remanufactured disc brake caliper with bracket included
• Steel piston construction with two 44.4 mm diameter pistons
• Oil emulsion finish in gray color for corrosion resistance
• Includes installation hardware kit (mounting bolts not included)
• Bleeder port size M7x1.0 and inlet port size M10x1.0
• Compatible with Lexus GS300, GS400, GS430, and SC430

Product Line Details: Unloaded Caliper w/Bracket

The Cardone Unloaded Caliper w/Bracket product line provides remanufactured calipers that come complete with the mounting bracket and necessary hardware kit for installation. This line is designed to simplify brake system repairs by offering a ready-to-install caliper assembly, excluding brake pads and mounting bolts. The 19-B2775 model fits select Lexus vehicles and features steel pistons for consistent braking force and longevity.

Technical Description and Features

This remanufactured disc brake caliper features two steel pistons with an outer diameter of approximately 44.4 mm, providing balanced clamping force on the brake rotor. The caliper is finished with an oil emulsion coating in gray, which helps resist corrosion and wear. The bleeder port size is M7x1.0, and the inlet port size is M10x1.0, matching OEM specifications for proper brake fluid flow and maintenance. The package includes the caliper, bracket, and a hardware kit to facilitate installation, though mounting bolts and brake pads are not included.

Compatible Vehicles and Common Applications

• Replacement for worn or leaking calipers on Lexus GS300, GS400, GS430, and SC430
• Addresses issues such as uneven brake pad wear or pulling to one side during braking
• Helps resolve symptoms of low brake pedal often caused by air in the brake system
• Suitable for brake system repairs requiring steel piston calipers
• Used when upgrading or restoring brake hydraulics to OEM standards

Installation Notes and Tips

• Use silicone grease on floating caliper mounting pins to ensure smooth operation
• Always use brake fluid recommended by the vehicle manufacturer (DOT 3 or DOT 4 as specified)
• Bleed the brake system thoroughly to remove air and prevent low brake pedal issues
• New hardware is included with the caliper, but verify if mounting bolts are required separately
• Do not interchange phenolic and steel piston calipers without confirming compatibility

Quality Assurance and Warranty

Cardone remanufactured calipers undergo rigorous testing to meet OEM performance standards. The 19-B2775 caliper is built to provide reliable braking function and corrosion resistance. Installation hardware is included to support proper fitment. For warranty details, refer to Cardone's standard coverage on remanufactured brake components.
