Cardone 19-B819 Disc Brake Caliper - Front Left

Overview of Cardone Unloaded Caliper w/Bracket for Toyota Pickup

The Cardone 19-B819 Unloaded Caliper w/Bracket is a remanufactured disc brake caliper designed specifically for Toyota Pickup models. Engineered to meet OEM specifications, this gray oil emulsion finished caliper ensures reliable braking performance and durability.

• Remanufactured disc brake caliper with bracket and hardware kit included
• Compatible with Toyota Pickup vehicles
• Steel piston with 57.15 mm outer diameter for consistent braking force
• Bleeder port size M7x1.0 and inlet port size M10x1.0 for proper hydraulic connections
• Oil emulsion finish in gray for corrosion resistance
• Installation hardware included; mounting bolts not included

About the Cardone Unloaded Caliper w/Bracket Product Line

The Cardone Unloaded Caliper w/Bracket product line offers remanufactured disc brake calipers that come complete with the necessary bracket and hardware kit for installation. This line is designed to provide a cost-effective replacement option while maintaining the quality and fitment standards required for specific vehicle applications such as the Toyota Pickup. The unloaded design means brake pads are not included, allowing for flexibility in pad selection.

Product Details and Specifications

This Cardone 19-B819 caliper features a single steel piston measuring 57.15 mm in diameter, providing reliable hydraulic pressure to the brake pads. The caliper’s gray oil emulsion finish helps protect against rust and wear. It includes a bleeder port sized M7x1.0 and an inlet port sized M10x1.0, ensuring compatibility with the Toyota Pickup’s brake hydraulic system. The package contains the caliper, bracket, and a hardware kit for installation, though mounting bolts are not included. This remanufactured part is designed to meet or exceed OEM standards for fit and function.

Common Applications and Issues Addressed

• Replacement for worn or leaking disc brake calipers on Toyota Pickup models
• Resolves brake pedal issues caused by caliper malfunction or air in the brake lines
• Addresses uneven braking or vehicle pull to one side during braking
• Eliminates brake squeal related to caliper hardware or piston problems
• Restores proper hydraulic pressure for consistent brake performance

Installation Notes and Tips

When installing the Cardone 19-B819 caliper on a Toyota Pickup, ensure the use of the recommended brake fluid type as specified by the vehicle manufacturer. The caliper comes with a hardware kit but does not include mounting bolts, so verify bolt condition before installation. Use silicone grease on floating caliper mounting pins to maintain smooth operation. Bleed the brake system thoroughly to remove any air and achieve a firm brake pedal feel.

Quality Assurance and Warranty

This remanufactured Cardone caliper undergoes rigorous testing to meet OEM quality standards. It is built to provide reliable braking performance and durability. Installation hardware is included to facilitate proper fitment. For warranty details, refer to Cardone’s standard coverage policies applicable to remanufactured brake components.
