Cardone 1G-1814 Rack and Pinion Assembly
Reliable Rack and Pinion Assembly for Chevrolet HHR
The Cardone Rack and Pinion Assembly 1G-1814 is a remanufactured steering component designed specifically for Chevrolet HHR models. Engineered to restore precise steering control, this manual rack and pinion assembly offers a durable aluminum casting and black finish to match OEM specifications.
Key Features of Cardone Rack and Pinion Assembly 1G-1814
- Compatible with Chevrolet HHR vehicles
- Remanufactured manual rack and pinion assembly
- Durable aluminum casting material for lightweight strength
- Black bellows and steering rack finish for corrosion resistance
- Includes inner tie rod ends and instruction sheet
- Rack length: 47.5 inches (1206.5 mm)
- Input shaft diameter: 0.747 inches (18.97 mm), length: 3.875 inches (98.43 mm)
- Distance between mounting holes: 17.125 inches (434.98 mm)
- Standard replacement grade type for reliable performance
About the Cardone Rack and Pinion Assembly Product Line
The Cardone Rack and Pinion Assembly line focuses on remanufactured steering components that meet or exceed OEM standards. This product line emphasizes quality restoration of steering gear and related components, providing a cost-effective solution for maintaining vehicle handling and safety. The 1G-1814 model is part of this line, offering a manual steering rack designed for precise fitment and dependable operation in Chevrolet HHR vehicles.
Detailed Product Description
This Cardone rack and pinion assembly features a robust aluminum casting that balances strength and weight, contributing to improved steering response. The black bellows and steering rack finish provide protection against environmental factors, helping to extend the service life of the component. The assembly includes inner tie rod ends but does not come with outer tie rods, mounting brackets, or gaskets/seals, so ensure compatibility with your existing hardware. The manual type steering rack is designed for direct replacement, with a rack length of 47.5 inches and precise mounting hole spacing to match Chevrolet HHR specifications.
Common Steering Issues Addressed by This Rack and Pinion Assembly
- Steering wheel play or looseness
- Difficulty in steering or heavy steering effort
- Uneven or inconsistent steering response
- Leaking or damaged steering rack components
- Noise or clunking sounds during steering
Installation Notes and Tips
Installation of the Cardone 1G-1814 rack and pinion assembly requires proper alignment and torque specifications to ensure optimal steering performance. Since mounting brackets and outer tie rods are not included, verify the condition of existing components before installation. Follow the included instruction sheet carefully and consider professional installation if unfamiliar with steering system repairs. Proper bleeding of the steering system after installation is recommended to avoid air pockets and ensure smooth operation.
Quality Assurance and Warranty Information
This remanufactured rack and pinion assembly undergoes rigorous testing to meet quality and performance standards. Cardone provides a limited warranty on this part, covering defects in materials and workmanship. For specific warranty details, refer to Cardone’s official documentation or contact authorized service providers.
| Brand | Cardone |
|---|---|
| Part Number | 1G-1814 |
| Position | Rack and Pinion Assembly |
| Bellows Color | BLACK |
| Casting Material | ALUMINUM |
| Distance Between Mounting Holes (in) | 17.125 |
| Distance Between Mounting Holes (mm) | 434.98 |
| E-Waste | NO |
| Gasket or Seal Included | NO |
| Grade Type | Standard Replacement |
| Input Shaft Diameter (in) | 0.747 |
| Input Shaft Diameter (mm) | 18.97 |
| Input Shaft Length (in) | 3.875 |
| Input Shaft Length (mm) | 98.43 |
| Mounting Brackets Included | NO |
| Outer Tie Rods Included | NO |
| Package Contents | Rack and Pinion; Instruction Sheet |
| Product Condition | Remanufactured |
| Rack Length (in) | 47.500 |
| Rack Length (mm) | 1206.50 |
| Steering Rack Color/Finish | BLACK |
| Thread Length (in) | 2.220 |
| Thread Length (mm) | 56.39 |
| Tie Rod Ends Included | INNER |
| Type | Manual |
This part fits 9 vehicles. Search below:
| Year | Make | Model | Submodel | Position | Notes |
|---|---|---|---|---|---|
| 2011 | Chevrolet | HHR | N/A | with Soft Ride Suspension ( (FE1) ); Includes Inner Tie Rods; Option Codes are on the Service Parts Identification Sticker; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly | |
| 2010 | Chevrolet | HHR | LS | N/A | with Soft Ride Suspension ( (FE1) ); Includes Inner Tie Rods; Option Codes are on the Service Parts Identification Sticker; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
| 2010 | Chevrolet | HHR | LT | N/A | with Soft Ride Suspension ( (FE1) ); Includes Inner Tie Rods; Option Codes are on the Service Parts Identification Sticker; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
| 2010 | Chevrolet | HHR | LS Panel | N/A | with Soft Ride Suspension ( (FE1) ); Includes Inner Tie Rods; Option Codes are on the Service Parts Identification Sticker; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
| 2010 | Chevrolet | HHR | LT Panel | N/A | with Soft Ride Suspension ( (FE1) ); Includes Inner Tie Rods; Option Codes are on the Service Parts Identification Sticker; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
| 2009 | Chevrolet | HHR | N/A | with Soft Ride Suspension ( (FE1) ); Includes Inner Tie Rods; Option Codes are on the Service Parts Identification Sticker; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly | |
| 2008 | Chevrolet | HHR | N/A | with Soft Ride Suspension ( (FE1) ); Includes Inner Tie Rods; Option Codes are on the Service Parts Identification Sticker; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly | |
| 2007 | Chevrolet | HHR | LS | N/A | Includes inner tie rods; compatible with electronic power steering systems featuring a manual rack.; Rack and Pinion Assembly |
| 2006 | Chevrolet | HHR | LS | N/A | Includes inner tie rods; compatible with electronic power steering systems featuring a manual rack.; Rack and Pinion Assembly |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
This part directly replaces or is cross-referenced with the following part numbers:
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
