Cardone 1G-26004 Rack and Pinion Assembly
Overview of Cardone Rack and Pinion Assembly 1G-26004
The Cardone Rack and Pinion Assembly 1G-26004 is a remanufactured steering component designed specifically for Toyota Prius and Prius Plug-In models. Engineered to restore precise steering control, this manual rack and pinion assembly features durable aluminum casting and a black finish for corrosion resistance.
- Remanufactured rack and pinion assembly for Toyota Prius and Prius Plug-In
- Constructed with aluminum casting material for strength and lightweight performance
- Black bellows and steering rack finish for durability
- Includes inner tie rod ends and instruction sheet
- Manual type steering rack with precise input shaft dimensions
Detailed Product Features and Specifications
This Cardone Rack and Pinion Assembly 1G-26004 is part of the Rack and Pinion Assembly product line, which focuses on providing standard replacement steering gear components. The assembly features a 19.688-inch (500.06 mm) distance between mounting holes and a rack length of 43.063 inches (1093.79 mm), ensuring proper fitment and alignment. The input shaft diameter measures 0.784 inches (19.91 mm) with a length of 1.750 inches (44.45 mm), designed for compatibility with the Toyota Prius and Prius Plug-In steering systems. The assembly comes with black bellows and a black steering rack finish to resist wear and environmental exposure. Inner tie rod ends are included, but outer tie rods, mounting brackets, and gaskets or seals are not part of the package.
Compatible Vehicles and Common Applications
This rack and pinion assembly is compatible with the following Toyota models:
- Toyota Prius
- Toyota Prius Plug-In
It is designed to address common steering issues such as:
- Excessive play or looseness in steering
- Difficulty in steering or stiff steering wheel
- Leaking or damaged steering rack components
- Uneven tire wear due to misaligned steering
- Noise or clunking sounds during steering maneuvers
Installation Notes and Tips
Installation of the Cardone 1G-26004 rack and pinion assembly requires professional tools and expertise. Note that mounting brackets and outer tie rods are not included and may need to be reused or replaced separately. Ensure proper alignment and torque specifications are followed to maintain steering performance and safety. The included instruction sheet provides guidance for installation procedures.
Quality Assurance and Warranty Information
This remanufactured rack and pinion assembly undergoes rigorous testing to meet OEM standards for fit, form, and function. Cardone's Rack and Pinion Assembly product line is known for delivering reliable replacement parts that restore steering precision. While specific warranty details are not provided here, Cardone typically offers limited warranties on remanufactured steering components to ensure customer confidence.
| Brand | Cardone |
|---|---|
| Part Number | 1G-26004 |
| Position | Rack and Pinion Assembly |
| Bellows Color | BLACK |
| Casting Material | ALUMINUM |
| Distance Between Mounting Holes (in) | 19.688 |
| Distance Between Mounting Holes (mm) | 500.06 |
| E-Waste | NO |
| Gasket or Seal Included | NO |
| Grade Type | Standard Replacement |
| Input Shaft Diameter (in) | 0.784 |
| Input Shaft Diameter (mm) | 19.91 |
| Input Shaft Length (in) | 1.750 |
| Input Shaft Length (mm) | 44.45 |
| Mounting Brackets Included | NO |
| Outer Tie Rods Included | NO |
| Package Contents | Rack and Pinion; Instruction Sheet |
| Product Condition | Remanufactured |
| Rack Length (in) | 43.063 |
| Rack Length (mm) | 1093.79 |
| Steering Rack Color/Finish | BLACK |
| Thread Length (in) | 2.017 |
| Thread Length (mm) | 51.23 |
| Tie Rod Ends Included | INNER |
| Type | Manual |
This part fits 16 vehicles. Search below:
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2015 | Toyota | Prius | N/A | with 15" Wheels; Includes Inner Tie Rods; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
| 2015 | Toyota | Prius | N/A | with 16" Wheels; Includes Inner Tie Rods; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
| 2015 | Toyota | Prius Plug-In | N/A | Includes inner tie rods; compatible with electronic power steering systems featuring a manual rack.; Rack and Pinion Assembly |
| 2014 | Toyota | Prius | N/A | with 15" Wheels; Includes Inner Tie Rods; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
| 2014 | Toyota | Prius | N/A | with 16" Wheels; Includes Inner Tie Rods; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
| 2014 | Toyota | Prius Plug-In | N/A | Includes inner tie rods; compatible with electronic power steering systems featuring a manual rack.; Rack and Pinion Assembly |
| 2013 | Toyota | Prius | N/A | with 15" Wheels; Includes Inner Tie Rods; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
| 2013 | Toyota | Prius | N/A | with 16" Wheels; Includes Inner Tie Rods; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
| 2013 | Toyota | Prius Plug-In | N/A | Includes inner tie rods; compatible with electronic power steering systems featuring a manual rack.; Rack and Pinion Assembly |
| 2012 | Toyota | Prius | N/A | with 15" Wheels; Includes Inner Tie Rods; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
| 2012 | Toyota | Prius | N/A | with 16" Wheels; Includes Inner Tie Rods; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
| 2012 | Toyota | Prius Plug-In | N/A | Includes inner tie rods; compatible with electronic power steering systems featuring a manual rack.; Rack and Pinion Assembly |
| 2011 | Toyota | Prius | N/A | with 15" Wheels; Includes Inner Tie Rods; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
| 2011 | Toyota | Prius | N/A | with 16" Wheels; Includes Inner Tie Rods; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
| 2010 | Toyota | Prius | N/A | with 15" Wheels; Includes Inner Tie Rods; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
| 2010 | Toyota | Prius | N/A | with 16" Wheels; Includes Inner Tie Rods; Electronic Power Steering with Manual Rack; Rack and Pinion Assembly |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
This part directly replaces or is cross-referenced with the following part numbers:
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
