Cardone 1G-26005 Rack and Pinion Assembly
Overview of Cardone Rack and Pinion Assembly 1G-26005
The Cardone Rack and Pinion Assembly 1G-26005 is a remanufactured steering component designed for precise manual steering control. Engineered for compatibility with Lexus HS250h and Scion tC models, this assembly ensures reliable performance and durability.
- Remanufactured rack and pinion assembly with black bellows and steering rack finish
- Constructed from lightweight aluminum casting material for strength and corrosion resistance
- Manual type steering rack with inner tie rod ends included
- Exact fit with 19.813 inches (503.24 mm) distance between mounting holes
- Input shaft diameter of 0.782 inches (19.86 mm) and length of 1.625 inches (41.27 mm)
- Rack length measures 42.167 inches (1071.03 mm) for proper fitment
- Includes rack and pinion assembly plus instruction sheet; no mounting brackets or outer tie rods included
Detailed Product Description
This Cardone Rack and Pinion Assembly 1G-26005 is a standard replacement part designed to restore steering precision and responsiveness in compatible vehicles. The assembly features a durable aluminum casting that balances strength with reduced weight, contributing to overall vehicle efficiency. The black bellows and steering rack finish provide corrosion resistance and a clean appearance. With an input shaft diameter of 0.782 inches and length of 1.625 inches, this manual rack and pinion assembly fits securely within the steering system of Lexus HS250h and Scion tC models. The included inner tie rod ends facilitate direct connection to the steering linkage, although outer tie rods and mounting brackets are not part of this package.
About the Cardone Rack and Pinion Assembly Product Line
The Cardone Rack and Pinion Assembly product line focuses on remanufactured steering components that meet OEM specifications for fit and function. This line offers standard replacement assemblies designed to provide reliable steering performance for various vehicle makes and models. The 1G-26005 part number represents a manual steering rack assembly tailored for specific Lexus and Scion applications, ensuring compatibility and ease of installation.
Common Steering Issues Addressed
- Steering wheel play or looseness
- Difficulty in steering or increased effort
- Leaking steering rack seals (note: gasket or seal not included)
- Uneven or noisy steering response
- Worn or damaged inner tie rod ends affecting steering alignment
Installation Notes and Tips
- Verify compatibility with Lexus HS250h or Scion tC before installation
- Ensure proper alignment of mounting holes spaced 19.813 inches apart
- Use appropriate tools to secure the input shaft with a diameter of 0.782 inches
- Inspect and replace outer tie rods and mounting brackets separately as needed
- Follow the included instruction sheet carefully for torque specifications and installation sequence
Quality Assurance and Warranty
This remanufactured Cardone Rack and Pinion Assembly 1G-26005 undergoes rigorous testing to meet industry standards for durability and performance. While the product does not include a gasket or seal, it is built to provide a reliable steering solution for compatible Lexus and Scion vehicles. Warranty coverage details should be confirmed with the distributor or installer.
| Brand | Cardone |
|---|---|
| Part Number | 1G-26005 |
| Position | Rack and Pinion Assembly |
| Bellows Color | BLACK |
| Casting Material | ALUMINUM |
| Distance Between Mounting Holes (in) | 19.813 |
| Distance Between Mounting Holes (mm) | 503.24 |
| E-Waste | NO |
| Gasket or Seal Included | NO |
| Grade Type | Standard Replacement |
| Input Shaft Diameter (in) | 0.782 |
| Input Shaft Diameter (mm) | 19.86 |
| Input Shaft Length (in) | 1.625 |
| Input Shaft Length (mm) | 41.27 |
| Mounting Brackets Included | NO |
| Outer Tie Rods Included | NO |
| Package Contents | Rack and Pinion; Instruction Sheet |
| Product Condition | Remanufactured |
| Rack Length (in) | 42.167 |
| Rack Length (mm) | 1071.03 |
| Steering Rack Color/Finish | BLACK |
| Thread Length (in) | 1.897 |
| Thread Length (mm) | 48.18 |
| Tie Rod Ends Included | INNER |
| Type | Manual |
This part fits 9 vehicles. Search below:
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2016 | Scion | tC | N/A | Includes inner tie rods; compatible with electronic power steering systems featuring a manual rack.; Rack and Pinion Assembly |
| 2015 | Scion | tC | N/A | Includes inner tie rods; compatible with electronic power steering systems featuring a manual rack.; Rack and Pinion Assembly |
| 2014 | Scion | tC | N/A | Includes inner tie rods; compatible with electronic power steering systems featuring a manual rack.; Rack and Pinion Assembly |
| 2013 | Scion | tC | N/A | Includes inner tie rods; compatible with electronic power steering systems featuring a manual rack.; Rack and Pinion Assembly |
| 2012 | Lexus | HS250h | N/A | Includes inner tie rods; compatible with electronic power steering systems featuring a manual rack.; Rack and Pinion Assembly |
| 2012 | Scion | tC | N/A | Includes inner tie rods; compatible with electronic power steering systems featuring a manual rack.; Rack and Pinion Assembly |
| 2011 | Lexus | HS250h | N/A | Includes inner tie rods; compatible with electronic power steering systems featuring a manual rack.; Rack and Pinion Assembly |
| 2011 | Scion | tC | N/A | Includes inner tie rods; compatible with electronic power steering systems featuring a manual rack.; Rack and Pinion Assembly |
| 2010 | Lexus | HS250h | N/A | Includes inner tie rods; compatible with electronic power steering systems featuring a manual rack.; Rack and Pinion Assembly |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
