Cardone 1G-2670 Rack and Pinion Assembly

Overview of Cardone Rack and Pinion Assembly 1G-2670

The Cardone Rack and Pinion Assembly 1G-2670 is a remanufactured steering component designed specifically for the Scion xB. Engineered to restore precise steering control, this manual rack and pinion assembly offers reliable performance with durable aluminum casting and a black finish.

• Remanufactured rack and pinion assembly for Scion xB
• Aluminum casting material for lightweight durability
• Manual steering type with inner tie rod ends included
• Black bellows and steering rack finish
• Precise mounting hole spacing of 19.813 inches (503.24 mm)
• Input shaft diameter of 0.793 inches (20.14 mm) and length of 1.625 inches (41.28 mm)
• Rack length of 43.25 inches (1098.55 mm) with 2.129 inches (54.08 mm) thread length

Details About the Rack and Pinion Assembly Product Line

The Cardone Rack and Pinion Assembly product line focuses on remanufactured steering gear components that meet standard replacement grade requirements. This line is designed to provide dependable steering performance by restoring original equipment specifications. The 1G-2670 part exemplifies this approach with its aluminum casting and manual steering configuration, tailored for the Scion xB.

Product Description and Specifications

This Cardone rack and pinion assembly features a black finish on both the bellows and the steering rack, contributing to corrosion resistance and a clean appearance. The assembly includes inner tie rod ends but does not come with outer tie rods, mounting brackets, or gaskets/seals. The input shaft measures 0.793 inches in diameter and 1.625 inches in length, ensuring compatibility with the Scion xB’s steering system. The mounting holes are spaced 19.813 inches apart, allowing for precise installation. The rack length is 43.25 inches, providing the correct fit and steering ratio for the vehicle.

Common Steering Issues Addressed by This Part

• Excessive play or looseness in steering
• Difficulty in steering or stiff steering wheel
• Leaking or damaged rack bellows
• Uneven tire wear due to misaligned steering
• Noise or clunking sounds during steering maneuvers

Installation Notes and Tips

Installation of the Cardone 1G-2670 rack and pinion assembly should be performed by a qualified technician familiar with Scion xB steering systems. Since mounting brackets and outer tie rods are not included, ensure these components are inspected and replaced if necessary. Proper alignment after installation is critical to maintain steering performance and tire longevity. Follow the included instruction sheet carefully for torque specifications and assembly procedures.

Quality Assurance and Warranty

This remanufactured rack and pinion assembly undergoes rigorous testing to meet standard replacement quality standards. Cardone provides a limited warranty on this part, covering defects in materials and workmanship. This warranty supports confidence in the product’s durability and fitment for the Scion xB.
