Cardone 26-3038E Rack and Pinion Assembly
Electronic Power Steering Rack for Altima
Restore steering response with this remanufactured CARDONE rack and pinion assembly for select Nissan Altima applications. Part number 26-3038E is built with new premium components, replaced rubber sealing parts, and a protective finish to support long service life and consistent steering feel.
Compatible with 2007-2013 Nissan Altima models equipped with hydraulic power steering, this assembly includes inner tie rods and is supplied with an Electronic Variable Orifice (EVO) component for the listed application.
Key Features
- Remanufactured Original Equipment-style fit for the listed Nissan Altima applications
- New spool valve seals and rack donut seals installed where applicable
- Specialized lubricant applied during remanufacturing for extended service life
- Factory test drive performed to verify operation under demanding conditions
- Protective coating helps resist corrosion and rust
- Steel and aluminum casting materials
- O-ring hose port type with M14 x 1.5 pressure port and M16 x 1.5 return port
- Includes rack and pinion, sealing kit, and instruction sheet
Product Details
CARDONE 26-3038E is a remanufactured rack and pinion assembly engineered for 2007-2013 Nissan Altima steering systems. The unit is rebuilt with replaced sealing components, polished micro-finish sleeves where applicable, and a specialized lubricant to help maintain smooth operation. CARDONE’s remanufacturing process also reduces raw material and energy use compared with producing a new part, while the factory test drive checks communication and performance before release.
This part cross-references Nissan OE numbers 49001JA00B and 49001JA000 for the same application.
Common Steering Issues It May Address
- Excessive steering play or loose steering feel
- Fluid leakage from rack seals or hose ports
- Hard steering during initial driving after startup
- Noise caused by internal bypass or worn sealing surfaces
- Steering that does not return to center after a turn
Installation Notes
Fits 2007-2013 Nissan Altima, hydraulic power steering, with Electronic Variable Orifice (EVO) component. Inner tie rods are included for the listed application. For warranty purposes, install an in-line filter, use the recommended OE fluid, and flush the steering system before operation. Bleed the system completely after installation to remove air and verify proper steering assist.
If the steering pump whines after replacement, inspect for air in the system and confirm the return line is not restricted or kinked. If the vehicle does not return to center, check front-end alignment and steering system flow before replacing additional components.
Quality Assurance
Each CARDONE rack and pinion assembly is remanufactured to rigorous quality and performance standards and tested on a factory drive cycle that simulates extreme operating conditions. The process uses new sealing components, protective coating, and application-specific lubrication to support durability and reliable operation in the listed Nissan Altima fitment.
| Brand | Cardone |
|---|---|
| Part Number | 26-3038E |
| Position | Rack and Pinion Assembly |
| Casting Material | Steel; aluminum |
| Distance Between Mounting Holes (in) | 11.63 |
| Distance Between Mounting Holes (mm) | 295.28 |
| E-Waste | Yes |
| FAQs | For the first few minutes of driving my car, the steering is hard |
| FAQs | I replaced the rack and now the power steering pump is whining. w |
| FAQs | Steering not returning to center coming out of a turn. what could |
| FAQs | The most likely cause of power steering pump whine is air in the |
| FAQs | The rack and pinion does not return to center by itself. the geom |
| FAQs | This symptom is classified as "morning sickness". this condition |
| Hose Port Type | O-ring |
| Input Shaft Diameter (in) | 0.75 |
| Input Shaft Diameter (mm) | 19.05 |
| Input Shaft Length (in) | 1.31 |
| Input Shaft Length (mm) | 33.32 |
| Number of Mounting Holes | 2 |
| Package Contents | Rack and pinion, sealing kit, instruction sheet |
| Pressure Port Thread Size | M14 x 1.5 |
| Product Condition | Remanufactured |
| Rack Length (in) | 42.13 |
| Rack Length (mm) | 1069.98 |
| Return Port Thread Size | M16 x 1.5 |
| Steering Rack Color | Black |
| Thread Length (in) | 1.92 |
| Thread Length (mm) | 48.64 |
| Tie Rod Ends Included | Yes |
| Total Turns Lock to Lock | 2.75 |
This part fits 23 vehicles. Search below:
| Year | Make | Model | Submodel | Body Type | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|---|---|
| 2013 | Nissan | Altima | Coupe | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |||
| 2012 | Nissan | Altima | Sedan | 3.5L | V6 | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |
| 2012 | Nissan | Altima | 2.5L | L4 | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | ||
| 2011 | Nissan | Altima | Sedan | 3.5L | V6 | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |
| 2011 | Nissan | Altima | Base | 2.5L | L4 | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |
| 2011 | Nissan | Altima | SL | 2.5L | L4 | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |
| 2011 | Nissan | Altima | S | 2.5L | L4 | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |
| 2010 | Nissan | Altima | Sedan | 3.5L | V6 | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |
| 2010 | Nissan | Altima | Base | 2.5L | L4 | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |
| 2010 | Nissan | Altima | SL | 2.5L | L4 | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |
| 2010 | Nissan | Altima | S | 2.5L | L4 | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |
| 2009 | Nissan | Altima | Sedan | 3.5L | V6 | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |
| 2009 | Nissan | Altima | Base | 2.5L | L4 | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |
| 2009 | Nissan | Altima | S | 2.5L | L4 | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |
| 2008 | Nissan | Altima | S | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |||
| 2008 | Nissan | Altima | Base | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |||
| 2008 | Nissan | Altima | Coupe | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |||
| 2008 | Nissan | Altima | SE | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |||
| 2008 | Nissan | Altima | SL | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |||
| 2007 | Nissan | Altima | S | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |||
| 2007 | Nissan | Altima | Base | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |||
| 2007 | Nissan | Altima | SE | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly | |||
| 2007 | Nissan | Altima | SL | N/A | Supplied with Electronic Variable Orifice (EVO) Component; Includes Inner Tie Rods; In-Line Filter available; For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system; with Hydraulic Power; Rack and Pinion Assembly |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
This part directly replaces or is cross-referenced with the following part numbers:
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
