Cardone 65-9107 Drive Shaft - Front

OE-Style Front Driveshaft for Ram 3500

The Cardone 65-9107 driveshaft / prop shaft is built for front driveline service on select 2000-2002 Dodge Ram 3500 trucks. It is engineered to match original equipment form, fit, and function, with dynamic balancing for smooth operation at speed.

Cardone’s Driveshaft / Prop Shaft line focuses on measured fitment, balanced performance, and durable construction for demanding truck applications. This steel front driveshaft is a direct replacement for the specified Ram 3500 configurations, including Dana Model 60 axle and NV241HD transfer case applications.

Key Features

• Part number 65-9107
• Steel driveshaft construction
• 28 3/4 in. overall length, measured from flange end to opposite U-joint center
• 2.5 in. tubing outer diameter
• Greasable design for serviceability
• Slip yokes are lubricated to help reduce premature wear
• 100% dynamically balanced at 3200 RPM for vibration-free operation and longer joint life
• Built to match OE form, fit, and function

Detailed Description

Cardone 65-9107 is a new front drive shaft for the 2000-2002 Dodge Ram 3500. It is specified for trucks with a Dana Model 60 axle and NV241HD transfer case, and it is measured at 28 3/4 inches (730 mm) from the end of the flange to the center of the U-joint on the opposite side. The steel tube construction and 2.5-inch outer diameter support the driveline requirements of heavy-duty pickup use.

This part cross-references Dodge 52105278AB for the same application. If you are replacing a worn front prop shaft on a Dodge Ram 3500, 65-9107 provides an OE-style replacement built around the original dimensions and balance requirements.

What It Helps Address

• Driveline vibration from an out-of-balance front driveshaft
• Clunking or driveline noise related to worn shaft components
• Premature wear from dry slip yokes
• Fitment issues caused by incorrect shaft length or configuration
• Loss of smooth front driveline operation in Ram 3500 service use

Installation Notes and Tips

Verify the vehicle is a 2000-2002 Dodge Ram 3500, front, with Dana Model 60 axle and NV241HD transfer case before ordering. Confirm the measurement method matches your original shaft: flange end to the center of the U-joint on the opposite side. Inspect related driveline components, including U-joints and mounting points, during replacement to ensure proper operation after installation.

Quality Assurance

Cardone engineers and tests prop shafts to match OE performance, and each unit is dynamically balanced for vibration-free operation at speed. The greasable design and lubricated slip yokes support long-term service in demanding truck applications. Part number 65-9107 is supplied as a new replacement driveshaft for the listed Dodge Ram 3500 fitments.
