Cardone 66-1535 CV Axle Assembly - Rear Right

Cardone CV Axle Assembly for Camaro Rear Right

Cardone 66-1535 is a new CV axle assembly engineered for rear right applications on select Chevrolet Camaro models. Built for OE-style fit and vibration-free operation, this axle is designed with attention to boot durability, shaft straightness, and seal performance.

Key Features

• Fits 2010-2013 Chevrolet Camaro, rear right
• Fits 2015 Chevrolet Camaro, rear right
• New axle retaining nut included for installation convenience
• Self-lock axle nut locking type
• Splined input shaft connection with 32 splines
• Splined output shaft connection with 33 splines
• Neoprene boots with added bellows where needed to reduce stress and ozone cracking
• Boot clamps are pneumatically crimped for a secure boot-to-housing seal
• High-temperature, high-torque grease is used for long-term joint protection
• Transmission seal diameter is precision-machined after heat treatment for proper seal life

Detailed Description

This Cardone CV axle assembly is built from the company’s CV driveline engineering experience and is intended to meet or exceed original equipment performance expectations. Each shaft is individually verified for straightness to help reduce vibration at speed, while the boot design and sealing details focus on the common failure points that affect CV joints over time. Cardone 66-1535 is a direct-fit driveline replacement for Chevrolet Camaro rear right service work where a complete axle assembly is required.

This part cross-references Chevrolet OE numbers 22813175 and 92238378 for the same application.

What It Helps Fix

• Clicking or snapping noises during hard turns
• Grease leakage around the axle boot or chassis
• Vibration during acceleration
• Grinding or rumbling from a worn CV joint
• ABS warning issues caused by damaged axle-area sensors or wiring during prior service

Installation Notes and Tips

• Do not let the CV axle hang unsupported during service.
• Use a torque wrench on the retaining nut and tighten to the vehicle manufacturer’s specification.
• Do not reuse a prevailing-torque lock nut; install a new nut.
• Replace transaxle seals when servicing CV drive axle assemblies.
• Inspect nearby sensor rings, sensors, and wiring before final assembly.

Quality Assurance

Cardone designs its CV drive axles around known failure modes such as boot cracking, seal wear, and shaft runout. The result is a replacement axle assembly built with verified straightness and controlled sealing details for consistent driveline performance on Chevrolet Camaro rear right applications.
