Cardone 66-2301 CV Axle Assembly - Front Right

Reliable CV Axle Assembly for Mazda 5

The Cardone CV Axle Assembly part number 66-2301 is designed specifically for Mazda 5 models, providing a precise fit and dependable driveline performance. This CV axle assembly ensures smooth power transfer from the transmission to the wheels, maintaining vehicle stability and handling.

• Compatible with Mazda 5 vehicles
• Compressed length of 22.17 inches for exact fitment
• Splined input and output shaft connection styles
• Output shaft with 28 splines for secure engagement
• Axle nut locking type: stake for reliable fastening
• ABS ring not included
• Complete axle assembly with instruction sheet included

About the Cardone CV Axle Assembly Product Line

The Cardone CV Axle Assembly line focuses on delivering complete axle solutions engineered to meet or exceed OEM specifications. Each assembly is factory balanced and inspected for run out to reduce vibrations and ensure smooth operation. This product line is tailored to provide direct replacement axles that simplify installation and restore driveline integrity for vehicles like the Mazda 5.

Product Details and Specifications

This Cardone CV Axle Assembly (part number 66-2301) features splined input and output shafts, with the output shaft having 28 splines to match the vehicle’s hub and transmission interface. The compressed length measures approximately 22.17 inches, ensuring proper fitment without modification. The axle nut locking type is stake, which requires staking to secure the nut and prevent loosening during operation. Note that this assembly does not include an ABS ring, so it is compatible with vehicles that do not require this component.

Common Applications and Problem Resolution

• Eliminates front-end grinding or clicking noises during turns
• Resolves vibrations or wheel wobble caused by worn CV joints
• Restores smooth power delivery to front wheels
• Fixes issues related to torn or ruptured CV axle boots
• Addresses driveline shifting or binding symptoms

Installation Notes and Tips

When installing the Cardone CV Axle Assembly 66-2301 on a Mazda 5, avoid letting the CV axles hang unsupported to prevent joint damage. Use a torque wrench to tighten the axle nut and avoid impact wrenches, as the stake locking nut requires staking rather than torque-only fastening. Always replace axle seals and follow the included instruction sheet for proper installation procedures.

Quality Assurance and Warranty

Each Cardone CV Axle Assembly undergoes 100% inspection for run out to minimize vibrations and ensure reliable performance. Shafts are factory balanced to maintain driveline smoothness. While specific warranty details are not provided here, Cardone products typically come with a limited warranty covering defects in materials and workmanship.
