Cardone 66-7516 CV Axle Assembly - Front Left

Overview of Cardone CV Axle Assembly 66-7516 for Volkswagen Passat

The Cardone CV Axle Assembly part number 66-7516 is designed specifically for Volkswagen Passat models. This CV axle assembly provides a reliable driveline component engineered to meet factory specifications and restore proper vehicle performance.

• Brand: Cardone
• Brand Line: CV Axle Assembly
• Part Number: 66-7516
• Compatible with Volkswagen Passat
• Compressed Length: 19.055 inches
• Axle Nut Locking Type: Bolt
• Output Shaft Spline Count: 36
• Input Shaft Connection Style: Bolt-on
• Output Shaft Connection Style: Splined
• ABS Ring Included: No
• Package Contents: Complete axle with instruction sheet

About the Cardone CV Axle Assembly Product Line

The Cardone CV Axle Assembly product line focuses on delivering complete axle assemblies that are factory balanced and inspected to reduce vibrations and ensure smooth driveline operation. These assemblies are designed with precise spline counts and connection styles to match vehicle specifications, such as the bolt-on input shaft and splined output shaft found in this 66-7516 model. Cardone’s CV Axle Assemblies are engineered to provide a direct replacement for worn or damaged axles in Volkswagen Passat vehicles.

Detailed Product Description

This Cardone CV Axle Assembly 66-7516 features a compressed length of approximately 19.05 inches, making it compatible with the Volkswagen Passat’s driveline geometry. The axle nut locking type uses a bolt style, which requires proper torque application during installation. The output shaft has 36 splines, ensuring a secure fit with the vehicle’s hub assembly. This assembly does not include an ABS ring, so it is intended for models without ABS sensor integration on the axle. The complete axle comes with an instruction sheet to assist with installation.

Common Issues Addressed by This CV Axle Assembly

• Eliminates clicking or grinding noises from worn CV joints
• Resolves vibrations or wobbling during turns
• Fixes axle shaft damage caused by torn CV boots
• Restores driveline stability after axle shaft failure
• Prevents drivetrain shifting or clunking noises under acceleration

Installation Notes and Tips

• Never allow the CV axle to hang unsupported during installation to avoid joint damage
• Use a torque wrench to tighten the bolt-type axle nut to manufacturer specifications
• Do not reuse prevailing torque lock nuts; always install new hardware as required
• Inspect axle shafts for run out to prevent vibrations after installation
• Follow the included instruction sheet carefully for proper fitment and assembly

Quality Assurance and Warranty

Cardone CV Axle Assemblies undergo 100% inspection for run out and balance to minimize vibrations and ensure reliable operation. The shafts are factory balanced and tested to meet OEM standards. While specific warranty details are not provided here, Cardone products typically come with a limited warranty covering defects in materials and workmanship. Always verify warranty terms with the product documentation or supplier.
