Cardone 66-9355 CV Axle Assembly - Rear Right

Cardone 66-9355 Rear Right CV Axle Assembly

Cardone 66-9355 is a new rear right CV axle assembly engineered for BMW driveline applications that demand smooth power transfer and stable operation. Built for 2005-2013 BMW 325xi, 330i, 330xi, 328i, 328xi, 328i xDrive, 335i, 335i xDrive, 135i, and M3 rear right positions, it is designed to address common axle wear concerns with OE-style fit and function.

Key Features

• New CV axle assembly for the rear right position
• Cardone CV Axle Assembly line focused on OE-level performance and durability
• Individually verified shaft straightness for reduced vibration
• Neoprene boots with added bellows where needed to resist stress and ozone cracking
• High-temperature, high-torque grease for long-lasting joint lubrication
• Pneumatically crimped boot clamps for a secure boot-to-housing seal
• Spindle nut included; M27 x 1.5 thread size
• Input shaft bolt-on connection with 6 bolt count and 30-spline output shaft

Product Details

The Cardone CV Axle Assembly line is built from engineering and testing experience focused on the common causes of CV axle failure. For this application, the axle shaft is checked for straightness to help maintain vibration-free performance, while the boot design and sealing approach are aimed at reducing the risk of grease loss and contamination. This part number, 66-9355, is a direct-fit driveline replacement for BMW rear right applications listed in the fitment data, including BMW 328i, 335i, 335i xDrive, and M3 models.

This part cross-references BMW 33207580946 and 33217553560 for the same application.

Common Problems This Part Can Address

• Clicking or snapping noises during hard turns and acceleration
• Grease on the chassis or suspension from a ruptured CV boot
• Vibration during acceleration caused by axle runout or wear
• Grinding or thumping from a worn outer or inner CV joint
• ABS warning issues after axle replacement when sensor components are disturbed

Installation Notes and Tips

• Fits 2005-2013 BMW 330xi, rear right; 2006-2007 BMW 330i, rear right; 2006 BMW 325xi, rear right; 2006 BMW 330xi, rear right; 2007-2008 BMW 328xi, rear right; 2007-2008 BMW 328i, rear right; 2007 BMW 328i, rear right; 2008-2013 BMW 328i, rear right; 2008-2013 BMW M3, rear right; 2008-2010 BMW 135i, rear right; 2008 BMW 335i, rear right; 2009 BMW 328i xDrive, rear right; 2009-2013 BMW 335i, rear right; 2009-2013 BMW 335i xDrive, rear right.
• Do not let the axle hang unsupported during service.
• Use a torque wrench on the retaining nut and tighten to manufacturer specifications.
• Replace the prevailing torque lock nut rather than reusing the old nut.
• Install new transaxle seals when replacing CV axle assemblies to help prevent leaks.
• Inspect ABS sensor rings, wiring, and nearby components during installation.

Quality Assurance

Cardone applies testing and engineering methods developed around CV drive axle failure prevention, including 100% shaft runout inspection to help ensure only shafts within specification are used in remanufacturing. The brand also uses precision-machined seal surfaces after heat treatment to support proper sealing and long service life.
