Cardone 67-6004 Fuel Injection Throttle Body

Electronic Throttle Body for Mustang

Cardone 67-6004 is a remanufactured electronic fuel injection throttle body for select 2005-2010 Ford Mustang applications. It is built to restore throttle response, airflow control, and OE-style fitment for Mustang owners replacing a worn or failing throttle body.

As part of the Cardone Fuel Injection Throttle Body line, this unit is remanufactured from an original equipment core and processed to meet application-specific engineering standards. The result is a direct-fit replacement for the Ford Mustang throttle body used in electronic throttle control systems.

Key Features

• Fits 2005-2010 Ford Mustang, N/A
• Cardone part number 67-6004
• Remanufactured electronic throttle body with electric actuation
• Throttle position sensor included
• Aluminum housing with gray/unfinished finish
• Oval inlet and round outlet design
• Specialized cleaning process helps preserve throttle bore shape for consistent airflow
• Final assemblies are tested for response time and airflow at multiple points
• Integrated high and low throttle position sensors are checked against OE characteristics

Product Details

This remanufactured throttle body is engineered for vehicles that rely on electronic throttle control, where the throttle plate, motor, and integrated sensors work with the PCM or TAC module to regulate incoming air. On the 2005-2010 Ford Mustang, a failing throttle body can trigger drivability concerns and fault codes, especially when the integrated sensors or actuator begin to drift from OE specifications. Cardone 67-6004 is renewed, inspected, and tested to support stable throttle operation and proper airflow management.

This part cross-references Ford 7R3Z9E926AA and 9R3Z9E926A for the same application.

Common Problems This Part Can Address

• Throttle response delay or inconsistent acceleration
• Check engine light related to throttle body or sensor faults
• Limp mode or reduced engine speed after throttle control failure
• Idle instability caused by worn throttle body components
• Airflow irregularities from a worn or contaminated throttle bore

Installation Notes

Install this throttle body on compatible 2005-2010 Ford Mustang models and perform the required relearn calibration procedure after installation. Consult the vehicle service manual for the correct reset and adaptation steps. Do not bypass the coolant hoses unless the OE service information specifically calls for rerouting; coolant routing is application-specific. Throttle body spacers are not recommended for this application.

Quality Assurance

Each Cardone remanufactured electronic throttle body is disassembled, inspected, cleaned, renewed, and tested before release. Damaged or worn components such as sensors, gears, connectors, and seals are replaced as needed, and final testing verifies critical functions including response time and airflow across multiple points. The remanufacturing process also reduces raw material and energy use compared with producing a new part.
