Carter P76432M Fuel Pump Module Assembly

Reliable Fuel Pump Module Assembly for Honda and Isuzu Vehicles

The Carter P76432M fuel pump module assembly is designed specifically for select Honda and Isuzu models, including the Axiom, Passport, and Rodeo. This electric fuel pump module ensures consistent fuel delivery and accurate fuel level readings for optimal engine performance.

• Fuel sending unit included for precise fuel level monitoring
• Electric pump type with a minimum flow rating of 23
• 12-volt operation compatible with standard vehicle electrical systems
• Wiring harness included with 4 wires, 20 gauge, and 300 mm length
• Quick connect outlet with 9.7 mm outside diameter and 5/16 thread size
• Plastic housing with oval white connector and blade terminals
• Strainer inlet type with included strainer for fuel filtration
• Top mount diameter of 113 mm with included gasket or seal

Detailed Product Description

The Carter P76432M fuel pump module assembly is engineered for specific fitment on Honda Axiom and Isuzu Passport and Rodeo models. This module features an integrated fuel sending unit, allowing for accurate fuel level readings directly from the tank. The electric pump operates at 12 volts and delivers a minimum flow rating of 23, ensuring steady fuel supply under various driving conditions. The included wiring harness has four 20-gauge wires with a length of 300 mm, facilitating straightforward electrical connections. The module’s plastic housing is durable and designed to withstand typical under-tank conditions. The fuel outlet uses a quick connect fitting with a 9.7 mm outside diameter and a 5/16 thread size, compatible with factory fuel lines. Additionally, the assembly includes a strainer inlet to help prevent debris from entering the fuel system, although it does not include a fuel filter. The top mount diameter measures 113 mm and comes with a gasket or seal to ensure a secure, leak-free installation.

Common Applications and Issues Addressed

• Replacement for failing or noisy fuel pumps in Honda Axiom and Isuzu Passport and Rodeo
• Resolves inconsistent fuel level readings due to faulty sending units
• Addresses fuel delivery problems causing engine hesitation or stalling
• Fixes fuel leaks by providing a new gasket or seal with the module
• Improves fuel system reliability by replacing worn or damaged pump modules

Installation Notes and Tips

• Ensure compatibility with your specific Honda or Isuzu model before installation
• Disconnect the battery before beginning to avoid electrical hazards
• Carefully remove the old fuel pump module to prevent damage to the fuel tank
• Use the included gasket or seal to prevent fuel leaks during installation
• Verify all electrical connections match the 4-wire harness and blade terminals
• Test the fuel pump operation before reassembling the vehicle components

Quality Assurance and Warranty

The Carter P76432M fuel pump module assembly is manufactured to meet OEM specifications for fit, form, and function. It undergoes rigorous quality control to ensure reliable performance and durability. This product includes a gasket or seal and wiring harness for a complete installation. While specific warranty details may vary, Carter products typically come with a limited warranty covering defects in materials and workmanship. Refer to the product documentation for exact warranty terms.
