Centric 111.01890 Drum Brake Shoe - Front or Rear
| Brand | Centric 111.01890 |
|---|---|
| Position | Front |
| Brake Shoe Width | 1.752 |
| Brake Shoe Width | 44.500 |
| Friction Material Attachment | Bonded |
| Mounting Hardware Included | No |
| Publication Dim | 229 x 44.5 |
| Rotor Outside Diameter | 9.016 |
| Rotor Outside Diameter | 229.000 |
| Shoe Qty [cntrc] | 4 |
| Weight [cntrc] kgs | 2.5 |
| Weight [cntrc] lbs | 5.5 |
| Product line | Centric Premium Brake Shoes |
| Fits | Chevrolet |
OE-style hardware. Includes pins and levers for an exact fit and function.
Asbestos-free friction. Specially formulated and dyno tested to meet or exceed OE specs.
Precision ground. Built for consistent fit and reliable brake shoe performance.
Cross-references Raybestos Brakes 189PG, 902-189 and 2087-149 for the same application. See all 13.
Centric Premium Brake Shoes for Drum Brake Service
Centric Premium Brake Shoes, part number 111.01890, are built for drum brake applications that require consistent pedal feel and precise shoe-to-drum contact. This Centric Premium Brake Shoes line is engineered for OE-style fit and function, with precision-ground surfaces and asbestos-free friction material for dependable braking performance.
Compatible With select drum brake applications, including Honda Civic and other vehicles that use a 229 mm / 9.016 in brake drum diameter and 44.5 mm / 1.752 in shoe width. If you are searching for Centric 111.01890 brake shoes for a drum brake repair, this part is built around the original equipment dimensions and hardware style.
Key Features
- Centric Premium Brake Shoes, part number 111.01890
- OE-style pins and levers included in the shoe design
- Precision-ground for accurate fit and consistent contact
- Asbestos-free friction compound
- Bonded friction material attachment
- Brake drum diameter: 229.000 mm / 9.016 in
- Brake shoe width: 44.500 mm / 1.752 in
- Mounting hardware not included
Product Details
The Centric Premium Brake Shoes product line focuses on direct-fit drum brake replacement with attention to dimensional accuracy and friction consistency. Part number 111.01890 uses an application-specific brake shoe profile with bonded friction material and OE-style components to help maintain proper drum engagement. For drivers servicing Honda Civic drum brake systems, Centric 111.01890 offers a straightforward replacement option when the original shoes are worn, uneven, or no longer delivering stable braking response.
This part cross-references Raybestos Brakes 189PG for the same application.
Common Brake Issues This Part Can Address
- Squealing or scraping from worn drum brake shoes
- Reduced parking brake holding performance
- Uneven braking caused by worn friction surfaces
- Longer pedal travel from brake shoe wear
- Poor drum-to-shoe contact from out-of-spec shoe dimensions
Installation Notes and Tips
Inspect the brake drum, wheel cylinder, return springs, and adjuster hardware before installation. Clean the backing plate contact points and verify drum diameter and shoe width match the application before assembly. Because mounting hardware is not included, reuse only serviceable components or replace worn hardware separately. After installation, adjust the drum brakes according to the vehicle service procedure and perform a careful road test.
Quality Assurance
Centric states that its Premium Brake Shoes are engineered and tested for quality and performance, with friction materials dyno tested to meet or exceed OE specifications. The asbestos-free friction compound and precision-ground construction support consistent fitment for drum brake service on select Honda Civic applications and other matching vehicles.
