Centric 120.62049 Disc Brake Rotor - Rear

Overview

Centric Premium Disc Brake Rotor 120.62049 is a rear vented rotor built for corrosion resistance and stable braking performance. It fits 1993-1997 Chevrolet Camaro, rear, and 1993-1997 Pontiac Firebird, rear.

Key Features

• Electrocoated finish for long-lasting corrosion protection.
• Designed to withstand up to 400 hours of salt water exposure without rusting.
• Vented rotor construction with straight vanes for airflow through the braking surface.
• Floating mounting type with a 5-lug bolt pattern.
• Nominal thickness of 20 mm and discard thickness of 18.4 mm.

Detailed Description

Centric Premium Disc Brake Rotors are engineered with an electrocoating finish that protects the rotor surface after installation, not just during storage. Part number 120.62049 uses a vented design with straight vanes, a 293 mm outside diameter, 47.6 mm height, and a 70.7 mm hub bore. The floating mounting style and 5-bolt pattern support direct replacement use on rear brake applications for the Chevrolet Camaro and Pontiac Firebird in the listed model years. This part cross-references PowerStop AR8249 and Dorman HELP 55027 for the same application.

What It Helps Address

• Surface rust on replacement brake rotors.
• Reduced airflow through the rotor during braking.
• Brake service needs on rear disc brake systems.
• Fitment matching for the correct rotor dimensions and bolt pattern.

Installation Notes and Tips

Verify rotor diameter, hub bore, bolt hole count, and thickness before installation. Confirm rear fitment for the vehicle and compare the old rotor to the new part number 120.62049 before assembly. Clean the hub mounting surface and inspect related brake components during service.

Quality Assurance

Centric Premium Disc Brake Rotors use an electrocoated finish intended to resist corrosion far beyond basic phosphate-coated rotors. Part number 120.62049 is built for consistent fitment on the listed rear applications.
