Centric 121.44096 Disc Brake Rotor - Rear

Overview of Centric C-TEK Standard Disc Brake Rotor 121.44096

The Centric C-TEK Standard Disc Brake Rotor 121.44096 is engineered for reliable braking performance on Toyota MR2 vehicles. Designed as a vented rotor with a smooth surface, it offers consistent heat dissipation and durability for everyday driving conditions.

• Compatible with Toyota MR2 models
• Part number: 121.44096
• Vented disc brake rotor with smooth surface
• Overall diameter: 11.063 inches (281 mm)
• Nominal thickness: 0.866 inches (22 mm)
• Discard thickness: 0.827 inches (21 mm)
• Overall height: 1.831 inches (46.5 mm)
• Floating disc mounting design
• 5 lug holes with 4.5 inch (114.3 mm) bolt circle diameter
• Weight approximately 14 lbs (6.36 kgs)

Detailed Product Description

This Centric C-TEK Standard Disc Brake Rotor 121.44096 is specifically designed for Toyota MR2 vehicles requiring a vented rotor to improve heat dissipation during braking. The rotor features a smooth surface type that ensures consistent pad contact and braking efficiency. With an outside diameter of 11.063 inches (281 mm) and a nominal thickness of 0.866 inches (22 mm), it meets OEM specifications for proper fit and function. The discard thickness of 0.827 inches (21 mm) indicates the minimum safe thickness before replacement is necessary. The rotor’s overall height is 1.831 inches (46.5 mm), and it uses a floating disc mounting system to accommodate thermal expansion and reduce stress. The 5 lug holes with a 4.5 inch (114.3 mm) bolt circle diameter and 0.571 inch (14.5 mm) stud hole diameter ensure secure mounting on the Toyota MR2 hub assembly.

About the C-TEK Standard Disc Brake Rotors Line

The C-TEK Standard Disc Brake Rotors line by Centric offers rotors designed to meet or exceed OEM specifications for standard replacement applications. This product line focuses on providing reliable braking performance with quality materials and precise manufacturing. The 121.44096 rotor is part of this line, delivering consistent braking characteristics suitable for daily driving and moderate use on Toyota MR2 vehicles.

Common Applications and Issues Addressed

• Replacement for worn or warped rotors on Toyota MR2
• Resolves brake pulsation caused by uneven rotor surfaces
• Addresses reduced braking efficiency due to rotor thickness below discard limits
• Improves heat dissipation to prevent brake fade during normal driving
• Restores proper rotor dimensions for safe and effective braking

Installation Notes and Tips

• Verify compatibility with Toyota MR2 model year before installation
• Inspect hub surface for cleanliness and damage prior to mounting
• Torque lug nuts to manufacturer specifications to ensure proper fit
• Check rotor thickness and discard limits during installation
• Bleed brake system after rotor replacement to maintain braking performance

Quality Assurance and Warranty

Centric C-TEK Standard Disc Brake Rotors are manufactured to meet strict quality standards and OEM specifications. While specific warranty details for part number 121.44096 should be confirmed with the supplier, Centric generally offers coverage against defects in materials and workmanship. This rotor is produced with precision machining and balanced to reduce vibration and ensure consistent braking performance on Toyota MR2 vehicles.
