Centric 320.35108F Disc Brake Rotor - Rear

Centric GCX Rear Brake Rotor for Sprinter and Crafter

The Centric GCX Elemental Protection Disc Brake Rotor, part number 320.35108F, is a rear vented rotor built for select Mercedes-Benz Sprinter and Volkswagen Crafter applications. Its fully coated disc finish and coated hat help protect exposed metal surfaces, while the smooth braking surface supports consistent rear brake service.

Key Features

• Fully coated disc finish for added surface protection
• Coated hat finish for improved corrosion resistance
• Vented rotor design with pillar vane style
• Smooth surface type for rear brake replacement service
• Behind-the-hub disc mounting configuration
• 6 mounting bolt holes with a 145.2 mm bolt circle diameter
• 11.929 in. outside diameter and 1.102 in. nominal thickness
• Part number 320.35108F for fitment verification

Product Details

Centric GCX Elemental Protection Disc Brake Rotors are built around corrosion-resistant coating coverage on both the disc and hat areas, making them a practical choice for rear brake maintenance on work vans and chassis cab applications. This rotor measures 303 mm in outside diameter, 28 mm nominal thickness, and 93 mm overall height, with a 120 mm center hole diameter and 170 mm hat ID. The vented construction and pillar vane layout support heat management during repeated braking events. Fits 2024 Mercedes-Benz Sprinter 3500, rear; Fits 2024 Mercedes-Benz Sprinter 3500XD, rear; Fits 2022-2023 Mercedes-Benz Sprinter 3500, rear; Fits 2018-2023 Mercedes-Benz Sprinter 3500XD, rear; Fits 2021 Mercedes-Benz Sprinter 3500, rear; Fits 2019-2020 Mercedes-Benz Sprinter 2500, rear; Fits 2019-2020 Mercedes-Benz Sprinter 3500, rear; Fits 2010-2018 Mercedes-Benz Sprinter 3500, rear; Fits 2016-2017 Volkswagen Crafter Van, rear; Fits 2008-2015 Volkswagen Crafter Van, rear; Fits 2007-2009 Dodge Sprinter 3500, rear.

What It Helps Address

• Rear brake rotor wear on Mercedes-Benz Sprinter 3500 and Sprinter 3500XD models
• Corrosion on exposed rotor surfaces from road moisture and salt
• Brake pulsation caused by worn or uneven rear rotors
• Heat buildup during repeated stop-and-go commercial driving
• Service replacement needs on Volkswagen Crafter Van rear brake systems

Installation Notes and Tips

Verify rear axle configuration, brake package, and model year before ordering. This rotor is listed for rear applications only and uses a behind-the-hub mounting style with six bolt holes. Confirm dimensions against the original rotor, including outside diameter, center hole diameter, bolt circle diameter, and overall height. Part number 320.35108F should be matched to the vehicle application before installation.

Quality Assurance

Centric GCX Elemental Protection rotors are engineered with coated surfaces and application-specific dimensions for direct replacement use on listed Mercedes-Benz Sprinter, Volkswagen Crafter, and Dodge Sprinter rear brake applications. This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application.
