Centric 320.65128F Disc Brake Rotor - Front

Centric GCX Front Brake Rotor for Ford F-150

The Centric GCX Elemental Protection Disc Brake Rotor, part number 320.65128F, is a front vented rotor built for 2004-2008 Ford F-150 and 2006-2008 Lincoln Mark LT 6-lug upgrade applications. It features a fully coated disc finish, coated hat, smooth surface, and ABS tone ring included for a direct-fit front brake service.

Centric’s GCX Elemental Protection line focuses on corrosion resistance and consistent rotor finish, making it a practical choice for truck and SUV brake maintenance where exposed brake components see frequent moisture and road contamination.

• Fits 2004-2008 Ford F-150, front
• Fits 2006-2008 Lincoln Mark LT, front
• Part number 320.65128F
• Fully coated disc finish with coated hat for added corrosion protection
• Vented rotor design with straight vanes and smooth braking surface
• Outside diameter: 12.992 in. / 330.0 mm
• Nominal thickness: 1.181 in. / 30.0 mm
• Discard thickness: 1.122 in. / 28.5 mm
• ABS tone ring included
• Hub & rotor mounting style for 6-lug upgrade kit applications

Brake Rotor Details

This Centric GCX rotor is engineered for front axle use on Ford F-150 and Lincoln Mark LT models listed above. The 6-lug pattern, 135.0 mm bolt circle, 86.9 mm center hole diameter, and 91.9 mm overall height support the specified hub-and-rotor setup. The rotor uses a vented, straight-vane construction with a smooth friction surface to support stable brake contact and consistent service replacement. If you are searching for a front brake rotor for a 2004-2008 Ford F-150 6 lug upgrade kit or a 2006-2008 Lincoln Mark LT front rotor, 320.65128F matches the listed application data.

Common Problems This Rotor Addresses

• Brake pulsation from worn or below-spec front rotors
• Corrosion on exposed rotor surfaces and hat areas
• Uneven braking feel caused by rotor surface wear
• Service replacement needs for 6-lug front hub and rotor upgrade kits
• ABS-related service concerns where a tone ring is required

Installation Notes

Verify the vehicle’s front hub-and-rotor configuration before ordering. For the listed Ford F-150 and Lincoln Mark LT applications, the notes specify a separate hub and rotor arrangement and indicate the spindle nut should be replaced, using 124.65901. Confirm rotor dimensions, bolt circle, center hole diameter, and ABS tone ring requirements against the vehicle before installation. Proper brake cleaning, torque procedures, and bedding-in after installation help support even pad transfer and consistent pedal feel.

Quality Assurance

Centric GCX Elemental Protection rotors are built with coated surfaces to help resist corrosion in everyday driving conditions. Part number 320.65128F is specified for the listed front applications and dimensions, supporting a direct replacement selection for Ford F-150 and Lincoln Mark LT brake service.
