Centric 320.80013F Disc Brake Rotor - Front or Rear

Overview of Centric GCX Elemental Protection Disc Brake Rotors

The Centric GCX Elemental Protection Disc Brake Rotors - Full Coating (part number 320.80013F) offer a fully coated, vented rotor solution designed to provide reliable braking performance. Engineered with a smooth disc surface and a coated hat finish, these rotors are built to resist corrosion and maintain structural integrity under demanding conditions.

• Fully coated disc and hat for enhanced corrosion resistance
• Vented rotor design with pillar-style vanes for improved heat dissipation
• Nominal thickness of 1.539 inches (39.1 mm) with discard thickness at 1.421 inches (36.1 mm)
• Overall height of 4.193 inches (106.5 mm) and outside diameter of 15 inches (381 mm)
• Five mounting bolt holes with a bolt circle diameter of 6.752 inches (171.5 mm)
• Hat shaped design with smooth surface finish for consistent pad contact

Product Line Details: Centric GCX Elemental Protection

The Centric GCX Elemental Protection Disc Brake Rotors - Full Coating line focuses on providing rotors with a full protective coating to combat rust and corrosion. This product line is ideal for vehicles operating in environments where exposure to moisture and road salts is common. The full coating extends rotor life and reduces maintenance needs, making it a practical choice for drivers seeking durability and consistent braking performance.

Technical Description and Specifications

This disc brake rotor features a vented design with pillar-style vanes that facilitate efficient heat dissipation during braking, helping to reduce brake fade. The rotor's nominal thickness is 1.539 inches (39.1 mm), with a discard thickness of 1.421 inches (36.1 mm), ensuring a clear service life indicator. The smooth disc surface provides even pad wear and consistent braking feel. The hat is coated to protect the mounting area from corrosion, and the rotor mounts behind the hub using five bolts spaced on a 6.752-inch (171.5 mm) bolt circle diameter. The center hole diameter measures 5.157 inches (131 mm), and the rotor weighs approximately 44 lbs (20 kg).

Applications and Problem Solving

• Replacement for worn or warped rotors causing brake pulsation or noise
• Upgrading corroded rotors to prevent premature failure in humid or salted road conditions
• Addressing reduced braking efficiency due to heat-related rotor degradation
• Suitable for vehicles requiring vented rotors with a 15-inch diameter and 5-bolt mounting pattern
• Ideal for models compatible with part number 320.80013F requiring a fully coated rotor

Installation Notes and Tips

Ensure the rotor is mounted behind the hub as specified. Verify the mounting bolt hole pattern and center hole diameter match the vehicle specifications. Clean the hub surface before installation to prevent uneven rotor seating. Use proper torque specifications on mounting bolts to avoid rotor warping. Since this rotor does not include bearings or ABS tone rings, reuse existing components or source separately as needed.

Quality Assurance and Warranty

Centric rotors are manufactured to meet or exceed OEM standards for fit, form, and function. The full coating process enhances corrosion resistance, contributing to longer service life. While specific warranty details are not provided here, Centric typically offers limited warranties covering defects in materials and workmanship. Refer to Centric's official documentation for complete warranty information.
