Cloyes 9-6105 Engine Timing Chain Guide - Upper

Brand	Cloyes 9-6105
Position	Upper
Material	Nylon
Length	2.528
Length	64.2112
Mounting Bracket Included	Yes
Height (uom:in)	1.79
Height (uom:mm)	45.466
Mounting Hole Diameter (uom:in)	.2507
Mounting Hole Diameter (uom:in)	.6085
Mounting Hole Diameter (uom:mm)	6.3677, 15.4559
Mounting Hole Quantity	2
Shoe Included	Yes
Width (uom:in)	1.153
Width (uom:mm)	29.2862
Product line	Timing Chain Guide
Fits	Mazda · 35 vehicles

Timing chain guide. Keeps the chain aligned for proper timing and smooth operation.

Nylon construction. Built for quiet operation and durable performance.

Mounting bracket included. Ready for a more complete timing system service.

Cross-references Four Seasons 96105, PE0112611 and PE7W12611 for the same application. See all 4.

$19.86Free shipping

In stock · usually ships same day before 1pm CST

Step 1 — Confirm fitment

Free return shipping if it doesn't fit when you check fitment here first.

Confirm position

Select your vehicle to confirm fitment

Verify this part fits before purchasing — free returns if it doesn't

Step 2 — Quantity

Free shipping to the continental U.S.

Free returns within 60 days if it doesn't fit when fitment is verified.

Not what you need? See all Engine Timing Chain Guide options

Cloyes 9-6105 Timing Chain Guide

The Cloyes 9-6105 is an engine timing chain guide built for upper timing chain service on select Mazda applications. It uses a nylon wear surface with an included mounting bracket and shoe to help maintain chain alignment and stable timing operation.

Key Features

Nylon guide surface for controlled timing chain movement
Mounting bracket included for direct service replacement
Shoe included for proper chain contact
Two mounting holes for secure installation
Dimensions: 2.528 in. length, 1.79 in. height, 1.153 in. width
Mounting hole diameters: 0.2507 in. and 0.6085 in.

Product Details

Cloyes timing chain guides are engineered with updated material and design technology to support quiet operation and durable performance in the timing system. Part number 9-6105 is intended for upper timing chain guide service on Mazda 2, CX-3, MX-5, MX-5 Miata, Mazda 3, Mazda CX-5, and Mazda 6 applications listed below. This part cross-references Four Seasons 96105 for the same application.

Compatible With: Fits 2016-2020 Mazda 2, Upper; Fits 2016-2020 Mazda CX-3, Upper; Fits 2016-2020 Mazda MX-5, Upper; Fits 2016-2020 Mazda MX-5 Miata, Upper; Fits 2012-2019 Mazda 3, Upper; Fits 2019 Mazda CX-5, Upper; Fits 2013-2017 Mazda CX-5, Upper; Fits 2018 Mazda 6, Upper.

Common Issues This Part Can Address

Timing chain noise from a worn guide surface
Chain misalignment in the upper timing system
Visible wear or damage on the original guide
Timing system service needs on high-mileage Mazda engines
Chain tracking concerns during engine repair

Installation Notes

For timing system service, inspect the chain, tensioners, guides, and sprockets together before reassembly. Confirm upper guide placement, mounting hole alignment, and chain contact surface condition during installation. Verify vehicle application by year, model, and position before ordering part number 9-6105.

Quality Assurance

Cloyes has specialized in automotive timing systems since 1921. The brand positions its timing components for OEM-level performance expectations and backs its products with technical support and an industry-leading warranty.

This part fits 35 vehicles

Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
