CSF 10699 A/C Condenser

Reliable A/C Condenser for Dodge Dart Vehicles

The CSF A/C Condenser part number 10699 is designed specifically for Dodge Dart models, providing efficient cooling performance. Built with a parallel flow construction, this condenser ensures optimal heat dissipation for your vehicle's air conditioning system.

• Parallel flow construction for improved cooling efficiency
• Core thickness of 5/8 inch for durability and performance
• Core dimensions: 17 1/3 inches width by 24 5/6 inches length
• Box dimensions: 33 1/2 inches length, 20 2/3 inches width, and 4 inches height
• Lightweight design at 11 1/2 lbs for easier handling
• Block fitting inlet and outlet tubes for secure connections
• Non-hazardous material compliant for safe handling

Technical Details and Construction

This CSF A/C Condenser (part number 10699) features a parallel flow design, which enhances heat exchange efficiency by allowing refrigerant to flow through multiple parallel channels. The core thickness of 5/8 inch balances durability with effective cooling capacity. With core dimensions measuring approximately 17 1/3 inches in width and 24 5/6 inches in length, this condenser fits precisely within the HVAC system of Dodge Dart vehicles. The block fitting inlet and outlet tubes provide reliable connections to the vehicle’s refrigerant lines, minimizing the risk of leaks.

Compatible Applications and Common Uses

• Replacement condenser for Dodge Dart A/C systems
• Addresses issues such as insufficient cooling or warm air from vents
• Resolves refrigerant leaks caused by damaged or corroded condensers
• Helps restore proper refrigerant flow and pressure in the A/C system
• Prevents overheating of the A/C compressor by maintaining efficient heat dissipation

Installation Notes and Tips

When installing the CSF A/C Condenser 10699, ensure the vehicle is compatible with this specific part number and model fitment. Proper evacuation and recharge of the refrigerant system are necessary after installation. Inspect all connections, especially the block fitting inlet and outlet tubes, for secure attachment to prevent leaks. It is recommended to check the condition of related components such as the receiver drier and expansion valve during replacement.

Quality Assurance and Warranty

CSF manufactures this A/C Condenser to meet OEM specifications for Dodge Dart vehicles, ensuring reliable performance and durability. The part is constructed from non-hazardous materials, adhering to safety standards. While specific warranty details are not provided, CSF products typically come with manufacturer-backed quality assurance to support long-term use.
