CSF 20002 Automatic Transmission Oil Cooler
| Brand | CSF 20002 |
|---|---|
| Box Height (in) | 10 3/7 |
| Box Length (in) | 34 1/4 |
| Box Weight (lbs) | 3 1/3 |
| Box Width (in) | 3 1/2 |
| Construction | parallel flow |
| Core Length | 25 2/7 |
| Core Thickness | 4/5 |
| Core Width | 3 |
| Hazardous Material | No |
| Inlet Tube | tube |
| Outlet Tube | tube |
| Fits | Kia and Hyundai · 10 vehicles |
Parallel-flow construction. Promotes efficient fluid cooling in a compact automatic transmission oil cooler.
Tube inlet and outlet. Simple tube connections keep installation straightforward.
Automatic transmission oil cooler for dependable fluid temperature control.
Cross-references Carlson 19069, Partslink Numbering System HY4050100 and 254604D900 for the same application. See all 3.
CSF 20002 Automatic Transmission Oil Cooler
The CSF 20002 automatic transmission oil cooler is a parallel-flow unit built to help manage transmission fluid temperature in select Kia and Hyundai applications. It is a direct-fit style cooler for 2006-2012 Kia Sedona, 2014 Kia Sedona, and 2007-2008 Hyundai Entourage applications.
Key Features
- Parallel-flow construction for efficient fluid cooling
- Core dimensions: 25 2/7 in. length, 3 in. width, and 4/5 in. thickness
- Tube-style inlet and outlet connections
- Compact packaging for handling and storage
- CSF part number 20002 for easy identification
Detailed Description
Built as an automatic transmission oil cooler, the CSF 20002 is designed around a parallel-flow core layout that promotes steady heat transfer as transmission fluid passes through the cooler. The core measures 25 2/7 inches long, 3 inches wide, and 4/5 inch thick, giving it a compact profile suited to the listed Kia Sedona and Hyundai Entourage fitments. If you are searching for a transmission cooler for 2006-2012 Kia Sedona, a transmission oil cooler for 2014 Kia Sedona, or a replacement cooler for 2007-2008 Hyundai Entourage, this CSF unit matches those applications. Cross-reference part numbers include Carlson 19069 and Partslink HY4050100 for the same application.
Common Problems It Can Help Address
- High transmission fluid temperatures during stop-and-go driving
- Heat buildup from towing or heavier vehicle use
- Reduced cooling performance from a damaged or leaking cooler
- Transmission fluid temperature control concerns in aging cooling systems
- Replacement needs after cooler corrosion or impact damage
Installation Notes and Tips
Confirm the inlet and outlet tube style before installation and compare the cooler dimensions to the original unit. Verify vehicle fitment by year and model before ordering, especially for 2006-2012 Kia Sedona, 2014 Kia Sedona, and 2007-2008 Hyundai Entourage applications. Inspect surrounding transmission cooler lines and mounting points for wear or damage during replacement.
Quality Assurance
CSF is a recognized cooling-system brand, and this part is built with a parallel-flow core design and non-hazardous materials classification. Part number 20002 is identified for the listed vehicle applications and cross-reference references.
| Year | Make | Model | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|
| 2014 | Kia | Sedona | 3.5L | V6 | N/A | — |
| 2012 | Kia | Sedona | 3.5L | V6 | N/A | — |
| 2011 | Kia | Sedona | 3.5L | V6 | N/A | — |
| 2010 | Kia | Sedona | 3.8L | V6 | N/A | — |
| 2009 | Kia | Sedona | 3.8L | V6 | N/A | — |
| 2008 | Hyundai | Entourage | 3.8L | V6 | N/A | — |
| 2008 | Kia | Sedona | 3.8L | V6 | N/A | — |
| 2007 | Hyundai | Entourage | 3.8L | V6 | N/A | — |
| 2007 | Kia | Sedona | 3.8L | V6 | N/A | — |
| 2006 | Kia | Sedona | 3.8L | V6 | N/A | — |
