CSF 2614 Radiator

Overview of CSF 1 Row Plastic Tank Aluminum Core Radiator

The CSF 1 Row Plastic Tank Aluminum Core Radiator (Part Number 2614) is designed specifically for Nissan Altima models. This radiator features a durable aluminum core combined with OE-style plastic tanks, providing reliable cooling performance for your vehicle.

• Core Thickness: 5/8 inch
• Core Width: 27 1/16 inches
• Core Length: 14 7/8 inches
• Core Material: Aluminum
• Tank Material: Plastic
• Inlet Diameter: 1 3/8 inches (right side)
• Outlet Diameter: 1 3/8 inches (left side)
• Down Flow Type Radiator
• Single Core Row Design
• Oil Cooler: 13 3/4 inches high-efficiency concentric type
• Cap Not Included

Details on the 1 Row Plastic Tank Aluminum Core Product Line

The CSF 1 Row Plastic Tank Aluminum Core line combines lightweight aluminum cores with OE-style plastic tanks to balance durability and cost-effectiveness. This product line is engineered to meet OEM specifications, ensuring compatibility and performance for vehicles like the Nissan Altima. The single-row core design supports efficient heat dissipation while maintaining a compact form factor.

Product Description and Specifications

This radiator features a 5/8 inch thick aluminum core measuring 27 1/16 inches wide and 14 7/8 inches long, optimized for the Nissan Altima cooling system. The plastic tanks are designed to match OEM standards, with inlet and outlet diameters both at 1 3/8 inches positioned on the right and left sides respectively. The down flow design facilitates effective coolant circulation through the single core row. Additionally, the integrated high-efficiency concentric oil cooler (13 3/4 inches) enhances engine cooling performance.

Compatible Applications and Common Issues Addressed

• Replacement radiator for Nissan Altima models requiring a 1 row aluminum core
• Resolves overheating caused by damaged or clogged radiator cores
• Addresses coolant leaks from cracked or worn plastic tanks
• Improves cooling efficiency in vehicles with failing OEM radiators
• Suitable for vehicles needing a down flow radiator configuration

Installation Notes and Tips

Ensure the radiator core dimensions and inlet/outlet sizes match your Nissan Altima's specifications before installation. This radiator does not include a cap, so reuse the existing cap or purchase a compatible CSF cap number 4503 separately. Properly bleed the cooling system after installation to avoid air pockets and ensure optimal performance.

Quality Assurance and Warranty Information

The CSF 1 Row Plastic Tank Aluminum Core Radiator (Part Number 2614) is manufactured to meet OEM quality standards. It is constructed without hazardous materials and designed for durability and reliable operation. Warranty details should be confirmed with the distributor or manufacturer, as they may vary.
