CSF 3004 Radiator

Overview of CSF 1 Row Plastic Tank Aluminum Core Radiator

The CSF 3004 radiator features a durable aluminum core combined with OE-style plastic tanks, designed for reliable cooling performance. This 1 Row Plastic Tank Aluminum Core radiator is engineered to meet specific vehicle cooling requirements, ensuring efficient heat dissipation and compatibility with various automotive applications.

• Core Thickness: 7/8 inch
• Core Width: 28 1/4 inches
• Core Length: 13 3/4 inches
• Core Material: Aluminum
• Tank Material: Plastic
• Inlet Diameter: 1 3/8 inches (left side)
• Outlet Diameter: 1 3/8 inches (right side)
• Down Flow Type Radiator
• Single Core Row Design
• Includes High-Efficiency Concentric Oil Cooler (11 13/16 inches)
• Cap Not Included (CSF Cap Number 4514 compatible)

Detailed Product Description

The CSF 3004 radiator is constructed with a 7/8 inch thick aluminum core that measures 28 1/4 inches wide and 13 3/4 inches long, providing a balance of cooling surface area and compact design. The plastic tanks are molded to OEM specifications, ensuring a precise fit and durability under typical operating conditions. This radiator uses a down flow design, which directs coolant from the top to the bottom, optimizing heat transfer for compatible vehicle cooling systems.

Equipped with a high-efficiency concentric oil cooler measuring 11 13/16 inches, this radiator supports additional engine oil cooling needs, which is critical for maintaining optimal engine temperatures in demanding driving conditions. The inlet and outlet diameters are both 1 3/8 inches, positioned on the left and right sides respectively, facilitating straightforward hose connections.

About the 1 Row Plastic Tank Aluminum Core Product Line

The CSF 1 Row Plastic Tank Aluminum Core product line focuses on combining lightweight aluminum cores with durable plastic tanks to replicate OEM radiator designs. This approach provides a cost-effective solution for vehicle owners seeking reliable cooling components without compromising on fitment or performance. The single core row design is suitable for applications where space constraints and cooling requirements align with this configuration.

Common Applications and Issues Addressed

• Replacement for leaking or damaged OEM radiators with plastic tanks
• Resolving overheating issues due to clogged or inefficient cores
• Upgrading cooling system components in vehicles requiring a down flow radiator
• Supporting engine oil cooling through integrated oil cooler functionality
• Addressing coolant flow restrictions caused by deteriorated radiator cores

Installation Notes and Tips

• Verify compatibility with your vehicle’s make and model before installation
• Ensure inlet and outlet hose diameters (1 3/8 inches) match existing connections
• Use the appropriate CSF radiator cap (part number 4514) as this radiator does not include a cap
• Inspect and replace any worn hoses or clamps during installation for optimal sealing
• Bleed the cooling system properly after installation to prevent air pockets

Quality Assurance and Warranty

CSF radiators, including the 3004 model, are manufactured to meet OEM standards with quality materials such as aluminum cores and plastic tanks. While specific warranty details may vary, CSF products typically come with a limited warranty covering defects in materials and workmanship. It is recommended to consult the product documentation or supplier for exact warranty terms.
