CSF 3260 Radiator

Overview of CSF 1 Row Plastic Tank Aluminum Core Radiator

The CSF 1 Row Plastic Tank Aluminum Core Radiator (Part Number 3260) is designed specifically for Chevrolet Equinox and Pontiac Torrent models. This radiator features a durable aluminum core combined with OE-style plastic tanks, providing reliable cooling performance for your vehicle.

• Core Thickness: 15/16 inch
• Core Width: 16 7/8 inches
• Core Length: 26 inches
• Aluminum core with plastic tanks
• Cross flow design for efficient heat dissipation
• Inlet and outlet diameters: 1 1/4 inch (left inlet, right outlet)
• Includes a 12-inch high-efficiency plate type oil cooler
• One core row configuration
• Cap not included

Detailed Product Description

This radiator from CSF’s 1 Row Plastic Tank Aluminum Core line combines a lightweight aluminum core with OE-style plastic tanks to maintain proper engine temperature in Chevrolet Equinox and Pontiac Torrent vehicles. The cross flow design enhances coolant flow across the core, improving heat exchange efficiency. With a core thickness of 15/16 inch and dimensions of 16 7/8 inches wide by 26 inches long, this radiator fits precisely within the engine bay specifications of the compatible models. The inlet and outlet diameters are both 1 1/4 inches, positioned on the left and right sides respectively, ensuring proper hose connections. Additionally, the integrated 12-inch high-efficiency plate type oil cooler supports engine oil temperature regulation, contributing to overall engine performance.

About the 1 Row Plastic Tank Aluminum Core Product Line

The CSF 1 Row Plastic Tank Aluminum Core product line focuses on combining aluminum cores with plastic tanks to replicate OEM radiator designs. This approach balances durability and cost-effectiveness while maintaining compatibility with factory specifications. Radiators in this line are engineered to meet the cooling demands of specific vehicle models, such as the Chevrolet Equinox and Pontiac Torrent, ensuring proper fitment and reliable operation.

Common Applications and Issues Addressed

• Replacement for leaking or damaged radiators in Chevrolet Equinox and Pontiac Torrent
• Resolves overheating caused by inefficient or clogged radiator cores
• Addresses coolant leaks from cracked plastic tanks
• Improves engine cooling performance with cross flow design
• Supports oil temperature control with integrated oil cooler

Installation Notes and Tips

• Verify radiator core dimensions and inlet/outlet positions before installation
• Ensure proper hose connections to 1 1/4 inch inlet (left) and outlet (right)
• Check compatibility with vehicle model year and engine configuration
• Bleed cooling system after installation to remove air pockets
• Cap not included; reuse existing radiator cap or purchase separately

Quality Assurance and Warranty

CSF radiators are manufactured to meet OEM standards, using high-quality aluminum cores and plastic tanks designed for durability and performance. This radiator is free of hazardous materials and undergoes quality control inspections to ensure reliability. Warranty information should be confirmed with the distributor or manufacturer, as it may vary by region.
