CSF 3368 Radiator

Overview of CSF 3368 Radiator for Honda Accord

The CSF 3368 radiator is designed specifically for Honda Accord models, providing reliable engine cooling with a durable aluminum core and plastic tanks. This radiator features a single-row core construction optimized for efficient heat dissipation in a compact design.

• Core thickness: 5/8 inch
• Core width: 29 11/16 inches
• Core length: 15 13/16 inches
• Aluminum core material with plastic tanks
• Down flow design with 1 1/4 inch inlet and outlet diameters on the left side
• Includes a high-efficiency 12 13/16 inch oil cooler (concentric type)
• OEM style plastic tanks and aluminum core for durability
• Single core row for streamlined cooling performance

Details on the 1 Row Plastic Tank Aluminum Core Product Line

The CSF 1 Row Plastic Tank Aluminum Core product line combines lightweight plastic tanks with a robust aluminum core to balance durability and heat transfer efficiency. This design supports a down flow cooling system, which is common in many Honda Accord models, ensuring compatibility and reliable performance. The multifit model approach allows this radiator to meet OEM specifications while accommodating slight variations in vehicle configurations.

Technical Description and Specifications

The CSF 3368 radiator features a 5/8 inch thick aluminum core measuring 29 11/16 inches wide and 15 13/16 inches long, providing a solid surface area for heat exchange. The plastic tanks reduce weight and resist corrosion, while the down flow design directs coolant from the top to the bottom of the radiator. Both the inlet and outlet have a 1 1/4 inch diameter located on the left side, facilitating straightforward hose connections. Additionally, the integrated 12 13/16 inch high-efficiency concentric oil cooler enhances engine oil temperature regulation, contributing to overall engine longevity.

Common Applications and Problem Solving

• Replacement for leaking or damaged radiators in Honda Accord vehicles
• Resolves overheating issues caused by inefficient cooling cores
• Addresses coolant flow restrictions due to clogged or corroded radiator cores
• Improves engine oil cooling with integrated oil cooler for better thermal management
• Suitable for Accord models requiring a down flow radiator with plastic tanks and aluminum core

Installation Notes and Tips

When installing the CSF 3368 radiator, ensure compatibility with your specific Honda Accord model year and engine configuration. The down flow design requires proper hose alignment on the left side for both inlet and outlet connections. Since the radiator does not include a cap, reuse the existing OEM cap or purchase separately if needed. Verify all mounting points and fittings before final installation to avoid leaks or improper fitment.

Quality Assurance and Warranty

CSF radiators are manufactured to meet OEM standards, using corrosion-resistant aluminum cores and durable plastic tanks. This radiator is free of hazardous materials and designed for long-term reliability. While specific warranty details are not provided here, CSF products typically come with a limited warranty covering defects in materials and workmanship. Consult the product documentation or manufacturer for exact warranty terms.
