CSF 3720 Radiator
| Brand | CSF 3720 |
|---|---|
| Box Height (in) | 5 11/16 |
| Box Length (in) | 31 1/4 |
| Box Weight (lbs) | 13 |
| Box Width (in) | 26 1/2 |
| Cap Included | No |
| Core Length | 18 7/16 |
| Core Material | Aluminum |
| Core Thickness | 7/8 |
| Core Width | 22 3/4 |
| Down Flow Or Cross Flow Type | Down Flow |
| Hazardous Material | No |
| Inlet Diameter | 1 5/16 Right |
| Inlet Length (in) | 23 1/4 |
| Inlet Width (in) | 1 7/8 |
| Oil Cooler (in) | 12 (high-efficiency Plate Type) |
| Outlet Diameter | 1 9/16 Left |
| Outlet Length (in) | 23 1/4 |
| Outlet Width (in) | 1 7/8 |
| Radiator Core Row Quantity | 1 |
| Tank Material | Plastic |
| Tech Note | O.E.M. style Plastic tanks & Aluminum core;with quick-connect oil cooler fittings. |
| Product line | 1 Row Plastic Tank Aluminum Core |
| Fits | Chevrolet, GMC, and Hummer · 20 vehicles |
OE-style design. Plastic tanks and an aluminum core for a direct-fit radiator replacement.
Wind tunnel tested. Validated for cooling performance in lab testing.
Quick-connect fittings. Includes quick-connect oil cooler connections for easier installation.
Cross-references Anchor 2855, APDI 8012855 and OSC 13017 for the same application. See all 9.
OE-Style Cooling Replacement for Select GM and Hummer Models
CSF 3720 is an OE-style radiator built with a plastic tank and aluminum core design for direct replacement cooling performance. It is engineered for select Chevrolet Colorado, GMC Canyon, Hummer H3, and Hummer H3T applications, with fitment that matches factory-style dimensions and hose connections.
Key Features
- 1-row radiator design with an aluminum core and plastic tanks
- Down-flow configuration for factory-style cooling layout
- Core thickness: 7/8 in.
- Core size: 22 3/4 in. wide x 18 7/16 in. long
- Inlet diameter: 1 5/16 in. right side
- Outlet diameter: 1 9/16 in. left side
- Integrated 12 in. high-efficiency plate-type oil cooler with quick-connect fittings
- OE-style plastic tanks and aluminum core construction
- CSF part number 3720
Product Details
CSF 3720 is part of CSF’s 1 Row Plastic Tank Aluminum Core line, a product line focused on OE-style radiator construction for direct-fit cooling system service. CSF manufactures radiators to high-performance standards and validates cooling performance through lab testing, including wind tunnel evaluation. This radiator is built for vehicles that need a factory-style replacement with the correct inlet and outlet placement, core dimensions, and oil cooler integration.
Fits 2009-2012 Chevrolet Colorado, N/A. Fits 2009-2012 GMC Canyon, N/A. Fits 2007-2010 Hummer H3, N/A. Fits 2009-2010 Hummer H3T, N/A. Fits 2006 Hummer H3, N/A, upgraded model.
This part cross-references Spectra Premium CU2855 for the same application.
Common Cooling System Issues It Can Address
- Leaking radiator tanks or core seams
- Restricted coolant flow from an aging radiator
- Overheating caused by reduced heat transfer efficiency
- Damaged or clogged integrated oil cooler passages
- Fitment problems from a non-OE-style replacement radiator
Installation Notes
Verify radiator dimensions, inlet and outlet orientation, and oil cooler connection style before installation. This radiator uses a down-flow layout with quick-connect oil cooler fittings, so matching the factory configuration is important for proper installation. Confirm the vehicle’s cooling system is fully drained and inspected for contamination before replacing the radiator.
Quality Assurance
CSF radiators are manufactured in ISO/TSO-certified facilities and are engineered for cooling performance validation. The brand reports more than 30 million radiators sold worldwide across over 50 years of production experience.
| Year | Make | Model | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|
| 2012 | Chevrolet | Colorado | 5.3L | V8 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2012 | GMC | Canyon | 5.3L | V8 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2011 | Chevrolet | Colorado | 5.3L | V8 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2011 | GMC | Canyon | 5.3L | V8 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2010 | Chevrolet | Colorado | 5.3L | V8 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2010 | GMC | Canyon | 5.3L | V8 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2010 | Hummer | H3 | 3.7L | L5 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2010 | Hummer | H3 | 5.3L | V8 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2010 | Hummer | H3T | 3.7L | L5 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2010 | Hummer | H3T | 5.3L | V8 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2009 | Chevrolet | Colorado | 5.3L | V8 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2009 | GMC | Canyon | 5.3L | V8 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2009 | Hummer | H3 | 3.7L | L5 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2009 | Hummer | H3 | 5.3L | V8 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2009 | Hummer | H3T | 5.3L | V8 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2009 | Hummer | H3T | 3.7L | L5 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2008 | Hummer | H3 | 5.3L | V8 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2008 | Hummer | H3 | 3.7L | L5 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2007 | Hummer | H3 | 3.7L | L5 | N/A | OE style design ensures optimal fitment and performance.; 1 Row Plastic Tank Aluminum Core |
| 2006 | Hummer | H3 | 3.5L | L5 | N/A | Upgraded Model; 1 Row Plastic Tank Aluminum Core |
