CSF 3727 Radiator

OE-Style Cooling Replacement

CSF radiator Part Number 3727 is an OE-style replacement built with an aluminum core and plastic tanks for direct-fit cooling performance. It is engineered for vehicles that need a cross flow radiator with quick-connect outlet pipe and quick-connect oil cooler fittings.

Key Features

• Aluminum core with plastic tanks for OE-style construction
• Cross flow design with 1-row core layout
• Core dimensions: 24 1/2 in. length, 19 3/16 in. width, 1 1/4 in. thickness
• Inlet diameter: 1 5/16 in. left; outlet diameter: 1 1/2 in. right
• 11 1/2 in. high-efficiency plate-type oil cooler
• Quick-connect outlet pipe and quick-connect oil cooler fittings
• Cap not included
• CSF Part Number 3727

Detailed Description

CSF Part Number 3727 is a radiator assembly designed around OE-style fitment and cooling layout. The aluminum core and plastic tank construction follows the factory-style design used on 2013-2021 Buick Encore and 2015-2020 Chevrolet Trax applications, with a 2021 Chevrolet Trax listing also confirmed. CSF manufactures radiators to controlled performance standards and validates cooling performance through laboratory wind tunnel testing. This radiator includes an integrated high-efficiency plate-type oil cooler and uses quick-connect fittings for the outlet pipe and oil cooler connections.

This part cross-references Monroe Shocks & Struts (e.g., 95298552, GM3010562) for the same application.

Vehicle Fitment

• Fits 2013-2021 Buick Encore, N/A; OE Style Design; RPO-LUV Eng.
• Fits 2021 Chevrolet Trax, N/A; OE style design ensures optimal fitment and performance.
• Fits 2015-2020 Chevrolet Trax, N/A; OE Style Design; Korea Built

Common Repair Uses

• Replacing a leaking or cracked radiator tank
• Restoring coolant flow after internal core restriction
• Addressing overheating caused by reduced heat transfer
• Replacing a damaged radiator with integrated oil cooler connections
• Returning factory-style cooling performance on Buick Encore and Chevrolet Trax models

Installation Notes

Verify inlet and outlet orientation before installation: inlet is 1 5/16 in. left and outlet is 1 1/2 in. right. Confirm the vehicle uses the listed cross flow layout and quick-connect oil cooler fittings. Transfer any required vehicle-specific components from the original radiator if applicable, and inspect hoses, clamps, and cooling system seals before refilling and bleeding the system.

Quality Assurance

CSF radiators are manufactured to high-performance standards and produced in ISO/TSO-certified facilities. The brand has supplied radiators worldwide for more than 50 years and uses engineering validation to support cooling performance consistency.
