CSF 3795 Radiator
| Brand | CSF 3795 |
|---|---|
| Core Thickness | 1 1/4 |
| Core Width | 19 |
| Core Material | Aluminum |
| Tank Material | Plastic |
| Core Length | 28 3/4 |
| Inlet Diameter | 1 1/2 right |
| Outlet Diameter | 1 1/2 left |
| Down Flow Or Cross Flow Type | Cross flow |
| Radiator Core Row Quantity | 1 |
| Cap Included | No |
| Box Height (in) | 6 7/16 |
| Box Length (in) | 35 15/16 |
| Box Weight (lbs) | 13 |
| Box Width (in) | 24 1/8 |
| Hazardous Material | No |
| Inlet Length (in) | 19 1/2 |
| Inlet Width (in) | 1 1/2 |
| Outlet Length (in) | 19 1/2 |
| Outlet Width (in) | 1 1/2 |
| Tech Note | O.e.m. style plastic tanks & aluminum core. |
| Fits | Ford · 4 vehicles |
OE-style design. Plastic tanks and an aluminum core mirror original equipment construction.
Cross-flow layout. Engineered for efficient cooling performance.
Wind tunnel tested. Validated in lab for cooling performance.
Cross-references BBB Industries 13559, FB5Z 8005 C and FO3010343 for the same application. See all 3.
CSF 3795 Radiator for Ford Explorer
The CSF 3795 radiator is an OE-style replacement built with an aluminum core and plastic tanks for the 2016-2019 Ford Explorer Ecoboost. It is engineered as a cross-flow radiator with a single-row core to match the factory cooling layout and support consistent engine temperature control.
Key Features
- OE-style plastic tanks with aluminum core construction
- Cross-flow design for factory-style cooling system routing
- Core thickness: 1 1/4 in.
- Core dimensions: 19 in. wide x 28 3/4 in. long
- Inlet: 1 1/2 in. right side
- Outlet: 1 1/2 in. left side
- Single-row radiator core
- Cap not included
Product Details
CSF part number 3795 is designed for direct replacement use in the Ford Explorer cooling system. The radiator uses an aluminum core for efficient heat transfer and plastic end tanks to follow the original equipment style layout. CSF manufactures radiators to high-performance standards and validates cooling performance through laboratory wind tunnel testing, with broad application coverage across many vehicle platforms. This part cross-references Bosch 13559 for the same application.
Common Cooling System Issues It May Address
- Coolant leaks from a damaged or aging radiator
- Overheating caused by restricted heat dissipation
- Cracked or weakened plastic tank assemblies
- Reduced cooling efficiency from a clogged or corroded core
- Factory radiator replacement needs after wear or impact damage
Installation Notes and Tips
Fits 2016-2019 Ford Explorer, N/A, Ecoboost. Verify inlet and outlet orientation before installation: inlet is 1 1/2 in. on the right and outlet is 1 1/2 in. on the left. Confirm radiator dimensions, hose routing, and mounting points against the original unit before final assembly. The radiator cap is not included, so reuse or replace the cap as needed based on the vehicle’s cooling system specification.
Quality Assurance
CSF states that its factories are ISO/TSO certified and that its radiators are engineered and tested for cooling performance validation. The brand has supplied radiators worldwide for more than 50 years and offers extensive model coverage across major vehicle applications.
| Year | Make | Model | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|
| 2019 | Ford | Explorer | 2.3L | L4 | N/A | Ecoboost |
| 2018 | Ford | Explorer | 2.3L | L4 | N/A | Ecoboost |
| 2017 | Ford | Explorer | 2.3L | L4 | N/A | Ecoboost |
| 2016 | Ford | Explorer | 2.3L | L4 | N/A | Ecoboost |
