CSF 6055 Intercooler

CSF 6055 Intercooler for Sprinter

The CSF 6055 intercooler is an OE-style replacement built for 2007-2009 Dodge Sprinter 2500 and Dodge Sprinter 3500 applications with an EGR cooler. It uses an aluminum tube-and-fin core with plastic end tanks and drop-in fitment dimensions for straightforward service replacement.

Key Features

• OE-style tube and fin core design
• Aluminum core construction with plastic tanks
• Core dimensions: 25 3/16 in. length, 7 15/16 in. width, 2 1/2 in. thickness
• 2 1/4 in. inlet and outlet tubes
• Designed and engineered for direct-fit replacement
• Fits 2007-2009 Dodge Sprinter 2500 and 2007-2009 Dodge Sprinter 3500 with EGR cooler

Detailed Description

CSF part number 6055 is an intercooler designed for Dodge Sprinter diesel applications that require an OE-style layout. The tube-and-fin core design follows factory-style packaging, while the aluminum core helps manage charge-air cooling in a direct replacement format. With 2 1/4-inch inlet and outlet connections, this CSF intercooler is built around the original fitment profile for 2007-2009 Dodge Sprinter 2500 and Dodge Sprinter 3500 models equipped with an EGR cooler. This part number 6055 is a practical choice when replacing a damaged or leaking factory intercooler on Sprinter vans.

This part cross-references Chrysler/Mopar 68013636AA and 68014095AA for the same application.

Common Replacement Reasons

• Cracked or leaking intercooler end tanks
• Reduced boost pressure from damaged charge-air cooling components
• Heat-related performance loss in the intake charge path
• Corrosion or physical damage to the original intercooler assembly
• Factory intercooler replacement on a 2007-2009 Dodge Sprinter 2500 or 3500

Installation Notes

Verify OE-style tube and fin intercooler dimensions before installation. Confirm inlet and outlet tube size, mounting points, and EGR cooler-equipped application details on the vehicle before replacing the original unit. Compare the existing intercooler to CSF 6055 to ensure the core length, width, and thickness match the factory layout.

Quality Assurance

CSF designs and engineers its cooling components for direct-fit service replacement and application-specific coverage. Part number 6055 is built to match the OE-style configuration used on the listed Dodge Sprinter models.
