Dana Spicer 3-26-757 Double Cardan CV H Yoke - Front

Double Cardan CV H Yoke for Front Driveline Service

The Dana Spicer FSGR 3-26-757 is a steel Double Cardan CV H yoke built for front driveline applications that require precise joint geometry and durable fitment. It is engineered for 1350 series use and matches the 2.875 universal joint centerline specification called out for select Ford Super Duty trucks.

Demand genuine Spicer components when replacing driveline parts on a Ford F-250 Super Duty or Ford F-350 Super Duty. The 3-26-757 is designed around Dana engineering, testing, and manufacturing standards to deliver consistent driveline performance in demanding service.

Key Features

• Part number: 3-26-757
• Brand: Dana Spicer FSGR
• Part type: Double Cardan CV H yoke
• Series: 1350
• Material: steel
• Bearing diameter: 1.188 in.
• Center-to-center dimension: 2.875 in.
• Inside dimension: 2.656 in.
• Outside dimension: 3.875 in.
• Swing diameter: 4.682 in.
• Joint angle #1: 26 degrees

Product Details

This Spicer driveline yoke is built for front drive shaft service where correct geometry matters. The 1350 series design, steel construction, and listed dimensions help ensure the yoke matches the intended universal joint setup on 1999-2004 Ford F-250 Super Duty and 1999-2004 Ford F-350 Super Duty front applications with a 2.875 universal joint centerline and FSGR configuration. This part cross-references SKF UJ650 for the same application.

Common Problems It Can Help Address

• Worn or damaged front driveline yoke surfaces
• Incorrect universal joint fitment at the drive shaft connection
• Vibration caused by mismatched driveline geometry
• Noise from looseness or wear in the yoke interface
• Service replacement needs on front driveline assemblies

Installation Notes and Tips

Verify the 1350 series, 2.875 universal joint centerline, and listed dimensions before installation. Confirm front position fitment on the vehicle and compare the existing yoke to the bearing diameter, inside dimension, and swing diameter specifications. For Ford F-250 Super Duty and Ford F-350 Super Duty front driveline service, match the FSGR configuration exactly to avoid fitment issues.

Quality Assurance

Spicer parts are backed by Dana’s design, engineering, testing, and manufacturing processes, which are used together to support consistent part quality and driveline performance. The 3-26-757 is a genuine Spicer component.

Vehicle Fitment

• Fits 1999-2004 Ford F-250 Super Duty, front, with 2.875 Universal Joint Centerline; FSGR
• Fits 1999-2004 Ford F-350 Super Duty, front, with 2.875 Universal Joint Centerline; FSGR
