Delphi FG0144 Fuel Pump Module Assembly

Delphi FG0144 Fuel Pump Module Assembly

Delphi FG0144 is an in-tank electric fuel pump module assembly for gas applications, built for direct replacement service on select Chevrolet Lumina and Chevrolet Monte Carlo models. It includes the fuel level sender assembly, strainer, gasket or seal, and a float arm for a complete module-style repair.

Key Features

• In-tank electric fuel pump module assembly for gas fuel systems
• Maximum pressure: 109.0; system pressure: 52 psi
• Average flow rating: 17 with average current draw of 7
• Fuel level sender assembly included with 40.0 ohms empty and 250.0 ohms full
• Strainer included; internal strainer design
• Female quick connect outlet with 3 outlets and 0.375 outlet outside diameter
• 13.0-volt operation with 6-pin male terminals
• Gasket or seal included; regulator not included
• Vapor pressure sensor included

Detailed Description

This Delphi fuel pump module assembly is a standard replacement part engineered for OE-style service on 1999 Chevrolet Lumina with Refuel Vapor Recovery, 2000-2001 Chevrolet Lumina, and 1999 Chevrolet Monte Carlo with Refuel Vapor Recovery. Delphi draws on long OE supply experience and applies that knowledge to aftermarket fuel delivery components, giving buyers a replacement module built around the original system layout and electrical requirements. Delphi FG0144 is a practical choice when replacing a worn pump, sender, or module assembly in these applications.

This part cross-references Bosch 67419 for the same application.

What It Helps Fix

• Hard starting caused by low fuel pressure
• Engine stalling from a weak or failing in-tank pump
• Inaccurate fuel gauge readings from a worn sender
• Fuel delivery loss from a clogged or damaged module strainer
• Fuel system leaks at the module seal area

Installation Notes and Tips

Compatible With 1999 Chevrolet Lumina, 2000-2001 Chevrolet Lumina, and 1999 Chevrolet Monte Carlo in the listed configurations. Clean the fuel tank before installation to reduce the risk of premature pump failure and seal issues; Delphi notes fuel tank contamination as a leading cause of early failure, and a tank cleaning kit is recommended for this service. Verify connector style, outlet type, and system pressure before installation.

Quality Assurance

Delphi builds this module using OE heritage and application knowledge developed through long-term supplier experience with major automakers. The FG0144 is a standard replacement fuel pump module assembly intended to restore proper fuel delivery and sender function in the listed Chevrolet applications.
