Delphi FG0198 Fuel Pump and Strainer Set

Delphi FG0198 Fuel Pump and Strainer Set

Delphi FG0198 is an in-tank electric fuel pump and strainer set for gas applications that require a standard replacement with OE-based engineering. Built for 12-volt systems and a maximum pressure rating of 80 psi, it supports consistent fuel delivery for older Ford trucks and vans that depend on a stable fuel supply.

Fits 1989-1997 Ford Bronco II, Bronco, E-150 Econoline, E-150 Econoline Club Wagon, E-250 Econoline, E-350 Econoline, E-350 Econoline Club Wagon, F-150, F-250, F-250 HD, and F-350 applications listed below.

• Delphi FG0198 fuel pump and strainer set for in-tank installation
• 12.0-volt electric pump for gasoline fuel systems
• Maximum pressure rating: 80 psi; system pressure: 45 psi
• Average flow rating: 24 and average current draw: 10
• Female quick-connect outlet with 0.375 in. outlet outside diameter
• Includes gasket or seal and strainer; external strainer design
• Package contents include fuel pump and strainer set, seals, clips, splices, and instruction sheet
• OE heritage from a supplier with 100 years of original-equipment experience

OE-Based Fuel Delivery Replacement

FG0198 is built around Delphi’s original-equipment background, combining fuel system knowledge with a standard replacement design for select Ford applications. It is an in-tank fuel pump assembly for gas vehicles and uses a lead-wire terminal setup with two terminals. The pump connects through a female quick-connect outlet and includes the strainer and sealing components needed for the listed applications. This part cross-references Bosch 67000 and Airtex E2059MN for the same application.

Compatible Ford applications include 1990-1991 Ford F-150, 1992-1996 Ford F-250, and 1992-1997 Ford F-350, along with 1990-1996 Ford Bronco and 1992-1996 Ford E-Series vans. The Delphi FG0198 fuel pump and strainer set is also listed for 1997 Ford F-250 HD and 1989-1990 Ford Bronco II.

Common Problems This Part Addresses

• Hard starting caused by weak or inconsistent fuel pressure
• Engine stalling from inadequate fuel delivery
• Loss of power under load in Ford truck and van applications
• Fuel starvation from a worn in-tank pump or clogged strainer
• Fuel system noise or pressure drop tied to pump wear

Installation Notes and Tips

Verify tank style and module configuration before ordering, since the listed Ford applications require specific tank and module setups. Delphi notes that this part can only be used if the original Ford module is still in the tank. Clean the fuel tank before installation to reduce the risk of contamination-related pump failure, and Delphi recommends fuel tank cleaning kit FC01 for these applications. Confirm the outlet style, terminal type, and pressure requirements against the vehicle’s original unit before installation.

Quality Assurance

Delphi builds aftermarket fuel system parts using OE heritage and knowledge developed through decades of supplying original-equipment components to major automakers. FG0198 reflects that background with a standard replacement design for select Ford fuel pump applications.
