Delphi FG0232 Fuel Pump Module Assembly

Reliable Fuel Pump Module Assembly for Chrysler and Dodge Vehicles

The Delphi FG0232 fuel pump module assembly is designed to provide consistent fuel delivery for select Chrysler and Dodge models. Engineered for in-tank installation, this electric fuel pump module ensures proper fuel pressure and flow to maintain engine performance.

• Compatible with Chrysler 300M, Concorde, Intrepid, and LHS models
• 12.0-volt electric fuel pump with integrated fuel level sender assembly
• Includes regulator, gasket, and external strainer for efficient fuel filtration
• Quick connect outlet with 0.375-inch outside diameter for secure fuel line attachment
• Standard replacement grade with 4 male blade terminals and 49 psi system pressure

Technical Specifications and Features

The Delphi FG0232 fuel pump module assembly operates at 12 volts and is designed for gasoline fuel systems. It features an external strainer inlet type and a quick connect outlet type with a single outlet port. The module includes a fuel pressure regulator to maintain a maximum pressure of 73 psi and a system pressure rating of 49 psi, ensuring stable fuel delivery under various operating conditions. The assembly comes with a gasket and strainer to prevent contaminants from entering the fuel system. It has four male blade terminals with resistance values ranging from 60 ohms (full) to 1050 ohms (empty), supporting accurate fuel level readings via the included fuel level sender assembly. The average current draw is 14 amps, and the average flow rating is 23 liters per hour, suitable for the specified Chrysler and Dodge vehicles.

Applications and Common Issues Addressed

• Restores proper fuel pressure and flow in Chrysler 300M, Concorde, Intrepid, and LHS models
• Replaces faulty or failing in-tank fuel pump modules causing engine hesitation or stalling
• Solves fuel level sender malfunctions for accurate fuel gauge readings
• Addresses fuel contamination issues with included external strainer and gasket
• Eliminates electrical connection problems with four blade terminals for secure wiring

Installation Notes and Tips

Installation of the Delphi FG0232 fuel pump module assembly requires removal of the fuel tank to access the in-tank pump. Ensure the vehicle’s battery is disconnected before beginning work to prevent electrical hazards. Use the included gasket to create a proper seal and prevent fuel leaks. Verify that the quick connect outlet is securely attached to the fuel line to avoid disconnections. Check all four blade terminals for proper connection and orientation during installation. Follow the vehicle manufacturer’s service manual for detailed removal and installation procedures specific to Chrysler 300M, Concorde, Intrepid, and LHS models.

Quality Assurance and Warranty Information

Delphi fuel pump modules are manufactured to meet or exceed OEM specifications for reliable performance and durability. The FG0232 is a standard replacement grade part backed by Delphi’s quality standards. While specific warranty terms may vary, Delphi typically offers coverage against defects in materials and workmanship. Refer to the product documentation or Delphi’s official resources for detailed warranty information.
