Delphi FG0509 Fuel Pump Module Assembly

Reliable Fuel Pump Module Assembly for Honda Passport and Isuzu Rodeo

The Delphi FG0509 fuel pump module assembly is designed to provide consistent fuel delivery for your Honda Passport or Isuzu Rodeo. Engineered for gas-powered vehicles, this in-tank electric fuel pump ensures efficient operation and precise fuel level monitoring.

• Electric fuel pump module assembly with integrated fuel level sender
• Compatible with 12.0-volt systems for gas fuel types
• Includes internal strainer and fuel strainer inlet for clean fuel flow
• Quick connect outlet with 0.375-inch outside diameter and dual outlet ports
• Four male blade terminals for secure electrical connections
• Includes gasket/seal and splice kit for proper installation
• System pressure rated at 44 psi with maximum pressure up to 109 psi
• Average flow rating of 23 and average current draw of 5 amps
• Vapor pressure sensor integrated for accurate fuel system monitoring

Technical Details and Features

The Delphi FG0509 fuel pump module assembly is a standard replacement part designed specifically for in-tank installation in Honda Passport and Isuzu Rodeo models. It operates on a 12-volt electrical system and is optimized for gasoline fuel types. The pump features an internal strainer and a strainer-type inlet to prevent contaminants from entering the fuel system, enhancing longevity and performance. The quick connect outlet with a 0.375-inch outside diameter and two outlet ports facilitates straightforward fuel line connections. The module includes a fuel level sender assembly with resistance values ranging from 80 ohms (full) to 290 ohms (empty), providing accurate fuel gauge readings. The four male blade terminals ensure reliable electrical connectivity, while the included gasket and splice kit support a secure and leak-free installation.

Compatible Vehicles and Applications

This fuel pump module assembly is compatible with the following vehicles:

• Honda Passport (gasoline models)
• Isuzu Rodeo (gasoline models)

It is designed to address common fuel delivery issues such as inconsistent fuel pressure, fuel pump failure, inaccurate fuel level readings, and fuel contamination problems.

• Resolves fuel pump failure or weak fuel pressure
• Corrects inaccurate fuel gauge readings due to faulty sender
• Prevents fuel contamination with internal strainer and inlet strainer
• Eliminates electrical connection issues with blade terminals
• Maintains proper system pressure for optimal engine performance

Installation Notes and Tips

When installing the Delphi FG0509 fuel pump module assembly, ensure the vehicle’s fuel system is depressurized before removal. Use the included gasket and splice kit to secure connections and prevent leaks. Verify the orientation of the fuel level sender assembly and confirm all electrical terminals are properly connected. This module is designed for in-tank installation; handle with care to avoid damage to the internal strainer and float arm. Follow vehicle-specific service manual instructions for safe and correct installation procedures.

Quality Assurance and Warranty

Delphi fuel pump modules are manufactured to meet or exceed OEM specifications, ensuring reliable performance and durability. The FG0509 is a standard replacement grade part backed by Delphi’s quality standards. It includes a vapor pressure sensor for enhanced fuel system diagnostics. Warranty coverage details vary by distributor but typically include protection against defects in materials and workmanship.
