Delphi FG0945 Fuel Pump Module Assembly

Delphi Fuel Pump Module Assembly Overview

The Delphi FG0945 fuel pump module assembly is designed for reliable fuel delivery in Ford Escort and Mercury Tracer vehicles. This in-tank electric fuel pump ensures consistent fuel flow and pressure to maintain engine performance.

• Compatible with Ford Escort and Mercury Tracer models
• 12.0 Volt electric fuel pump with 30 GPH average flow rating
• Includes fuel level sender assembly with float arm
• External strainer inlet type with quick connect outlet
• Standard replacement grade with included gasket and strainer

Technical Specifications and Features

The Delphi FG0945 fuel pump module assembly operates at 12 volts and is designed for gasoline fuel systems. It features a maximum pressure rating of 80 psi and a system pressure of 44 psi, suitable for maintaining optimal fuel delivery. The pump has a 0.375 inch outlet outside diameter and a single quick connect outlet for secure fuel line attachment. The assembly includes six male pin terminals and an external strainer inlet to protect the pump from debris. A fuel level sender assembly with float arm is integrated, providing accurate fuel level readings. The package contains the fuel pump module assembly, seal, clips, and installation instructions for a complete replacement solution.

Applications and Problem Solving

• Replaces faulty or failing fuel pumps in Ford Escort and Mercury Tracer vehicles
• Resolves inconsistent fuel pressure or flow issues
• Addresses fuel level sender malfunctions for accurate gauge readings
• Eliminates fuel delivery interruptions caused by clogged strainers
• Restores proper engine performance affected by fuel pump wear

Installation Notes and Tips

Installation of the Delphi FG0945 fuel pump module assembly requires removal of the fuel tank to access the in-tank pump. Ensure all electrical connections use the six-pin male terminals provided. Replace the included gasket to prevent fuel leaks and verify the quick connect outlet is securely attached to the fuel line. Follow the included instructions carefully to avoid damage to the fuel system components. It is recommended to inspect the fuel tank and lines for contamination before installation.

Quality Assurance and Warranty

This Delphi fuel pump module assembly is a standard replacement part manufactured to meet OEM specifications for Ford Escort and Mercury Tracer models. The product includes a gasket and strainer to ensure proper sealing and filtration. Delphi provides quality assurance through rigorous testing to maintain consistent fuel delivery and durability. Warranty coverage details should be confirmed at the point of purchase.
