Delphi TA2278 Steering Tie Rod End - Inner

Delphi TA2278 Inner Tie Rod End

Delphi TA2278 is an inner steering tie rod end built for direct replacement service on select Toyota Pickup applications. It combines a straight, pre-greased design with a dust boot and coated finish to support consistent steering feel and dependable protection in everyday driving.

Key Features

• Fits 1979-1994 Toyota Pickup, inner steering position
• Pre-greased design for ready-to-install service
• Dust boot included to help protect the joint from contamination
• High-strength steel housing with steel tie rod construction
• Coated finish for added surface protection
• Male-to-male, straight configuration
• Mounting hardware included
• Standard replacement part number TA2278

Detailed Description

Delphi TA2278 is an inner tie rod end for Toyota Pickup steering systems, engineered as a standard replacement for the 1979-1994 Toyota Pickup, inner position. The part uses a high-strength steel housing, steel tie rod material, and a threaded stud design with clockwise thread direction on both ends. Delphi applies OE-focused dimensional and material analysis to help maintain proper compatibility between the replacement part and the original steering layout. This part cross-references MOOG Chassis Products ES2374 for the same application.

Delphi subjects its steering components to extreme temperature and corrosion testing, including exposure below -40 degrees C, above 120 degrees C, and extended salt spray testing. Those validation steps support the durability expected in steering service where alignment stability and joint integrity matter. If you are replacing a worn inner tie rod end on a Toyota Pickup, TA2278 provides a direct-fit service part for the inner steering linkage.

Common Problems This Part Can Help Address

• Excessive steering play or looseness at the inner tie rod
• Clunking or knocking from the steering linkage
• Uneven tire wear caused by worn steering components
• Imprecise steering response on Toyota Pickup models
• Contamination-related wear at the steering joint

Installation Notes and Tips

Verify the inner position and thread specifications before installation on your Toyota Pickup. Inspect the outer tie rod ends, steering rack components, and alignment settings at the same time, since wear in adjacent parts can affect steering performance. After installation, a professional wheel alignment is recommended to restore correct steering geometry.

Quality Assurance

Delphi builds this steering component using OE-oriented engineering and validation methods, including dimensional and material analysis for fit consistency. The part is tested for temperature extremes and corrosion resistance to support long-term service in demanding steering applications.
