Delphi TA2292 Steering Tie Rod End - Inner
| Brand | Delphi TA2292 |
|---|---|
| Position | Inner |
| Adjustable | No |
| Bearing Material | Plastic |
| Color | Gray |
| Dust Boot Included | Yes |
| Dust Boot Material | Choloroprene Rubber (CR) |
| End 1 Gender | Male |
| End 1 Thread Diameter | 17.0 |
| End 1 Thread Direction | Clockwise |
| End 1 Thread Pitch | 1.5 |
| End 2 Gender | Male |
| End 2 Thread Diameter | 14.0 |
| End 2 Thread Direction | Clockwise |
| End 2 Thread Pitch | 1.5 |
| Friction Material Thickness | Coated |
| Grade | Standard |
| Grade Type | Standard |
| Grease Fitting Included | Yes |
| Greaseable | Yes |
| Height | 87.0 |
| Housing Material | High Strength Steel |
| Item Grade | Standard Replacement |
| Length | 227.0 |
| Length Stud Center to End | 205.0 |
| Mounting Hardware Included | Yes |
| Pre-Greased | Yes |
| Stud Type | Threaded |
| Tie Rod Material | Steel |
| Type | Bent |
| Weight | 1.7 |
| Width | 44.5 |
| Fits | Toyota · 14 vehicles |
Standard replacement. OE expertise and dimensional analysis help ensure compatibility with the original part.
High-strength steel. Built with a coated steel housing for durable steering performance.
Pre-greased. Includes a grease fitting and dust boot for easier service and protection.
Cross-references Beck/Arnley 101-4009, Dorman - Premium TI75080XL and Mevotech Supreme MES3192 for the same application. See all 12.
Delphi TA2292 Inner Tie Rod End
Delphi TA2292 is a steering tie rod end built for inner steering linkage service on select Toyota trucks and SUVs. It combines a high-strength steel housing, coated finish, and pre-greased construction to support precise steering response in demanding road conditions.
Compatible with 1992-1995 Toyota 4Runner, inner; 1993-1998 Toyota T100, inner; and 1992-1995 Toyota Pickup, inner.
Key Features
- Part number TA2292 for direct reference and ordering
- Inner steering tie rod end for steering gear and related components
- High-strength steel housing with coated finish
- Pre-greased design with grease fitting included
- Dust boot included to help protect internal components
- Greaseable construction for serviceability
- Male threaded ends with clockwise thread direction
- Standard replacement grade for OE-style service
Detailed Description
Delphi TA2292 is engineered as an inner steering tie rod end for Toyota 4Runner, Toyota T100, and Toyota Pickup applications. The bent design, threaded stud construction, and OE-focused dimensional analysis help support proper steering linkage geometry and fitment. Delphi subjects its steering components to extreme temperature and corrosion testing, including sub-zero and high-heat exposure plus extended salt-spray evaluation, to verify durability in real-world conditions.
This TA2292 tie rod end uses a steel tie rod material, plastic bearing material, and chloroprene rubber dust boot. It is a standard replacement part with a 17.0 mm end 1 thread diameter, 14.0 mm end 2 thread diameter, and 1.5 thread pitch on both ends. This part cross-references MOOG Chassis Products ES3192 and Mevotech Supreme MES3192 for the same application.
What It Helps Address
- Loose or wandering steering feel
- Steering play caused by worn inner tie rod joints
- Clunking or knocking from the steering linkage
- Uneven tire wear related to steering geometry wear
- Reduced steering precision during lane changes and turns
Installation Notes and Tips
Verify inner position, thread direction, and thread diameter before installation. Because this is a steering component, a professional alignment is recommended after replacement. Inspect related steering and suspension parts for wear at the same time, including outer tie rod ends, boots, and adjacent linkage hardware.
Quality Assurance
Delphi applies OE engineering experience to its aftermarket steering portfolio and validates parts through dimensional and material analysis for OE-style compatibility. The TA2292 is tested for temperature extremes and corrosion resistance to support dependable service in Toyota 4Runner, Toyota T100, and Toyota Pickup steering systems.
| Year | Make | Model | Drive Type | Position | Notes |
|---|---|---|---|---|---|
| 1998 | Toyota | T100 | 4WD | Inner | — |
| 1997 | Toyota | T100 | 4WD | Inner | — |
| 1996 | Toyota | T100 | 4WD | Inner | — |
| 1995 | Toyota | 4Runner | — | Inner | — |
| 1995 | Toyota | Pickup | 4WD | Inner | — |
| 1995 | Toyota | T100 | 4WD | Inner | — |
| 1994 | Toyota | 4Runner | — | Inner | — |
| 1994 | Toyota | Pickup | 4WD | Inner | — |
| 1994 | Toyota | T100 | 4WD | Inner | — |
| 1993 | Toyota | 4Runner | — | Inner | — |
| 1993 | Toyota | Pickup | 4WD | Inner | — |
| 1993 | Toyota | T100 | 4WD | Inner | — |
| 1992 | Toyota | 4Runner | — | Inner | — |
| 1992 | Toyota | Pickup | 4WD | Inner | — |
