Dorman 527-104 Suspension Control Arm and Ball Joint Assembly - Front Right Upper

Dorman 527-104 Front Right Upper Control Arm

Dorman 527-104 is a direct replacement suspension control arm and ball joint assembly for specific Jaguar applications. It is built to restore OE-style steering response, directional stability, and consistent ride quality on the front right upper corner.

Key Features

• Direct replacement for the original equipment control arm and ball joint assembly
• Pre-greased for initial service readiness
• Ball joint is installed and machined into the assembly
• Steel control arm construction with black finish
• Rubber bushings included for suspension isolation
• Pinch-style ball joint stud with 14 mm thread diameter
• Light suspension grade type for the listed applications

Detailed Description

This Dorman control arm assembly is engineered for 2016-2017 Jaguar XE and 2016-2017 Jaguar XF front right upper applications, including 2017 Jaguar XE front right upper to VIN HA963512 and 2017 Jaguar XF front right upper to VIN HCY32048. The Dorman 527-104 combines the control arm and ball joint in one OE-style replacement part to help maintain proper suspension geometry and predictable handling. It uses a steel casting/forged design with rubber bushings and a pre-installed ball joint to match the original layout on the vehicle.

This part cross-references NI and T2H3192 for the same application.

What It Helps Address

• Front-end looseness or imprecise steering feel
• Clunking or knocking from worn upper suspension joints
• Uneven tire wear caused by suspension wear
• Directional instability during braking or cornering
• Excess movement from deteriorated bushings or ball joint wear

Installation Notes and Tips

Verify vehicle fitment by year, model, position, and VIN note before installation. This assembly is not adjustable and does not include mounting hardware. Because the ball joint is already installed and the unit is pre-greased, installation focuses on proper alignment of the front right upper suspension points and correct torque of the mounting locations.

Quality Assurance

Dorman uses an industry-focused evaluation process to validate fit, function, and suspension performance for the listed Jaguar XE and Jaguar XF applications. The result is a replacement assembly intended to deliver smooth ride characteristics, directional stability, and predictable dynamics in service.
