Dorman 531-670 Suspension Stabilizer Bar Bushing Kit - Front To Frame

Dorman 531-670 Stabilizer Bar Bushing Kit

Dorman 531-670 is a suspension stabilizer bar bushing kit built as a direct replacement for the original equipment on specific Nissan applications. It uses rubber construction and OE-style dimensions to restore a secure stabilizer bar mount at the front-to-frame location.

• Rubber stabilizer bar bushings for suspension service
• Inside diameter: 28 mm
• Outside diameter: 44 mm
• Width: 42 mm
• Assembled length: 40 mm
• Regular grade replacement part
• Bracket included: No
• Grease fitting included: No

OE-Style Replacement Fitment

This suspension stabilizer bar bushing kit is precision-engineered and tested for reliable replacement performance on select Nissan Sentra, Nissan 200SX, and Nissan NX models. It cross-references Delphi TD4072W for the same application. Use Dorman 531-670 when servicing the front stabilizer bar mount on 1991-1994 Nissan Sentra, 1995-1998 Nissan 200SX, 1991-1993 Nissan NX, and 1998-1999 Nissan Sentra built in Mexico.

What It Helps Address

• Front stabilizer bar movement at the frame mount
• Clunking or rattling from worn sway bar bushings
• Excess play in the stabilizer bar connection
• Loss of suspension control caused by deteriorated rubber bushings
• Noise from aged OE bushings on Nissan Sentra, 200SX, and NX applications

Installation Notes and Tips

Install at the front-to-frame stabilizer bar location only. Verify the bushing dimensions and vehicle build details before installation, especially for 1998-1999 Nissan Sentra models built in Mexico. Inspect the stabilizer bar and mounting surfaces for wear before assembly.

Quality Assurance

Dorman manufactures this part as a precision-engineered replacement and subjects it to rigorous testing to support dependable OE-style service on the listed Nissan applications.
