Dorman 540-924 Steering Tie Rod End Adjusting Sleeve - Right (Pitman Arm to Connecting Tie Rod)
| Brand | Dorman 540-924 |
|---|---|
| Position | Right (Pitman Arm to Connecting Tie Rod) |
| Material | Acero |
| Material | Steel |
| Thread Direction | Counterclockwise (left) |
| Thread Direction | Rotar en el sentido contrario a las agujas del reloj (izquierda) |
| Length | 656 |
| Color | Black |
| Color | Negro |
| Color | Noir |
| Clamps Included | No |
| Clamps Included | Non |
| End 1 Gender | Female |
| End 1 Gender | Hembra |
| End 2 Gender | Female |
| End 2 Gender | Hembra |
| Outside Diameter | 35 |
| Mounting Hardware Included | Oui |
| Mounting Hardware Included | Sí |
| Mounting Hardware Included | Yes |
| Grade Type | Reemplazo estándar |
| Grade Type | Standard replacement |
| Bolts Included | No |
| Bolts Included | Non |
| End 1 Thread Type | Media |
| End 1 Thread Type | Medium |
| Thread Type | Coarse |
| Thread Type | Grueso |
| Arandela incluida | No |
| Contenidos del paquete | 1 extremo del terminal de la dirección |
| Contenidos del paquete | 2 abrazaderas |
| Contenidos del paquete | 4 arandelas |
| Fits | Jeep · 4 vehicles |
Standard replacement. Precision-engineered and rigorously tested for reliable fit and function.
Steel construction. Provides durable strength for steering hardware applications.
Coarse threads. Helps ensure secure adjustment and dependable engagement.
Cross-references Delphi TA5849, Mevotech Original Grade GDS1051S and Mevotech Supreme MDS1051S for the same application. See all 7.
Dorman 540-924 Steering Tie Rod End Adjusting Sleeve
Dorman 540-924 is a steel steering tie rod end adjusting sleeve built as a standard replacement for specific steering linkage applications. It is precision-engineered and tested for reliable replacement performance on the vehicle it was made for, including 1987-1990 Jeep Wrangler right-side steering linkage service.
Key Features
- Steel construction for steering linkage durability
- Counterclockwise (left) thread direction
- Female end configuration on both ends
- Coarse thread design with 11/16 in. thread diameter and 18 pitch
- Black finish
- Standard replacement grade for direct-fit service
- Fits 1987-1990 Jeep Wrangler, right (Pitman Arm to Connecting Tie Rod)
Detailed Description
This steering tie rod end adjusting sleeve is used to connect and adjust steering linkage length during front-end alignment and tie rod service. Dorman 540-924 is designed for the right-side steering connection from the pitman arm to the connecting tie rod on 1987-1990 Jeep Wrangler models. The sleeve uses a metric, coarse-thread design with a left-hand thread direction, helping maintain proper steering geometry when replacing worn or damaged linkage components. This part cross-references Delphi TA5849 for the same application.
What It Helps Fix
- Loose or worn steering linkage adjustment points
- Improper toe setting after tie rod service
- Corrosion or damage on the original adjusting sleeve
- Steering play caused by worn linkage hardware
- Difficulty maintaining alignment on Jeep Wrangler steering components
Installation Notes and Tips
Verify thread direction before installation, since this sleeve uses a counterclockwise left-hand thread. Confirm the vehicle position and linkage orientation on 1987-1990 Jeep Wrangler right-side steering applications before assembly. Inspect adjacent tie rod ends, clamps, and steering hardware for wear so the alignment can be set correctly after replacement.
Quality Assurance
Dorman manufactures this part as a precision-engineered, rigorously tested replacement for the original steering sleeve on listed applications. It is built to standard replacement specifications for dependable fit and function on the intended Jeep Wrangler steering setup.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 1990 | Jeep | Wrangler | Right (Pitman Arm to Connecting Tie Rod) | — |
| 1989 | Jeep | Wrangler | Right (Pitman Arm to Connecting Tie Rod) | — |
| 1988 | Jeep | Wrangler | Right (Pitman Arm to Connecting Tie Rod) | — |
| 1987 | Jeep | Wrangler | Right (Pitman Arm to Connecting Tie Rod) | — |
