Dorman 590-669 Park Assist Camera - Rear

Overview of Dorman Park Assist Camera for Mazda 3

The Dorman 590-669 park assist camera is designed specifically for the Mazda 3, providing enhanced rear visibility to support safer parking and maneuvering. This black, weather-resistant camera offers a wide viewing angle and reliable performance under various driving conditions.

• Compatible with Mazda 3 models
• Voltage: 9V to 18V operation range
• Wide horizontal view angle of 194 degrees
• Vertical view angle of 142 degrees for comprehensive coverage
• Durable black plastic body with weather-resistant design
• Compact dimensions: 170mm length, 23mm width, 28.23mm depth
• Includes one park assist camera, no mounting bracket or display included

Technical Details and Specifications

The Dorman 590-669 park assist camera features a 16.15mm lens diameter that captures a broad field of view, minimizing blind spots behind the vehicle. Its black plastic body is engineered to withstand exposure to weather elements, ensuring consistent functionality. The camera operates within a voltage range of 9 to 18 volts, making it compatible with the electrical systems of Mazda 3 vehicles. With a horizontal viewing angle of 194 degrees and a vertical angle of 142 degrees, this camera provides a wide and clear image to assist drivers during parking and reversing maneuvers.

Applications and Problem Solving

• Improves rear visibility to reduce the risk of collisions while reversing
• Assists in tight parking situations by providing a clear view of obstacles
• Helps detect pedestrians or objects behind the vehicle
• Supports safer navigation in low-light or adverse weather conditions
• Replaces faulty or damaged park assist cameras on Mazda 3 models

Installation Notes and Tips

Installation of the Dorman 590-669 park assist camera requires basic automotive electrical knowledge. The camera does not include a mounting bracket or display, so existing hardware and monitor systems in the Mazda 3 should be used. Ensure the camera is securely mounted in the designated rear location and properly connected to the vehicle’s power supply within the specified voltage range. Testing the camera feed before finalizing installation is recommended to confirm proper operation and alignment.

Quality Assurance and Warranty

Dorman parts are manufactured to meet or exceed OEM standards for fit, form, and function. The 590-669 park assist camera undergoes quality checks to ensure durability and reliable performance. While specific warranty details may vary, Dorman typically offers a limited warranty covering defects in material and workmanship. Refer to the product documentation for exact warranty terms.
