Dorman 598-727 Integrated Control Module

Overview of the Dorman Integrated Control Module 598-727

The Dorman Integrated Control Module 598-727 is designed specifically for Jeep Compass and Jeep Patriot models. This remanufactured power module provides reliable electrical control without the need for programming, making it a practical replacement option for your vehicle's integrated control system.

• Dimensions: 10 inches length, 6.75 inches height, 5.75 inches width
• Connector: 7 black rectangular female connectors with blade configuration
• Terminals: 208 male blade and pin terminals for secure electrical connections
• Housing made from durable plastic material
• Comes as a remanufactured totally integrated power module
• No mounting hardware or wire harness included
• No programming required for installation

Detailed Product Description

The Dorman 598-727 Integrated Control Module is engineered to meet the electrical demands of Jeep Compass and Jeep Patriot vehicles. Its plastic housing ensures durability while maintaining a lightweight design. The module features seven black rectangular female connectors configured with blade terminals, totaling 208 male blade and pin terminals. This configuration supports a wide range of electrical connections necessary for integrated vehicle control. The module measures 10 inches in length, 6.75 inches in height, and 5.75 inches in width, allowing for a precise fit within the vehicle's electrical system. As a remanufactured unit, it offers a cost-effective solution without compromising functionality. Importantly, this module does not require programming, simplifying the replacement process.

Common Applications and Issues Resolved

• Replacement for faulty or damaged integrated control modules in Jeep Compass and Patriot
• Resolves electrical control failures affecting lighting, body, and other vehicle systems
• Addresses intermittent power issues related to the integrated power module
• Fixes connector or terminal corrosion problems causing poor electrical contact
• Restores proper function to blade-type connector systems within the vehicle

Installation Notes and Tips

• Ensure vehicle compatibility with Jeep Compass or Jeep Patriot models before installation
• Disconnect the battery prior to module replacement to prevent electrical shorts
• Carefully align the seven black rectangular female connectors to avoid damage to blade terminals
• Verify all 208 terminals are properly seated for secure electrical connections
• No programming is required, but confirm all connections are tight and secure before reassembly

Quality Assurance and Warranty Information

This Dorman Integrated Control Module 598-727 is a remanufactured part that undergoes thorough testing to meet OEM standards for performance and reliability. While mounting hardware and wire harnesses are not included, the module is designed for direct replacement without additional components. The product comes with a limited warranty covering defects in materials and workmanship, providing confidence in its durability and function for Jeep Compass and Jeep Patriot vehicles.
