Dorman 598-729 Integrated Control Module

Overview of the Dorman Integrated Control Module 598-729

The Dorman Integrated Control Module 598-729 is designed for reliable electrical management in select Dodge and Jeep vehicles. This remanufactured power module offers a precise fit and robust construction to support your vehicle's control systems without requiring programming.

• Dimensions: 10 inches length, 6.75 inches height, 5.75 inches width
• Connector Quantity: 7 rectangular black female connectors
• Terminal Quantity: 208 male blade terminals with pin type configuration
• Housing Material: Durable plastic for long-lasting performance
• Remanufactured integrated control module, no programming required

Detailed Product Description

The Dorman 598-729 Integrated Control Module is engineered to meet the electrical control needs of Dodge Caliber, Jeep Compass, and Jeep Patriot models. Its plastic housing ensures durability while maintaining a lightweight profile. The module features seven black rectangular female connectors, each equipped with 208 male blade terminals arranged in a blade and pin configuration to ensure secure and efficient electrical connections. Measuring 10 inches in length, 6.75 inches in height, and 5.75 inches in width, this module is designed to fit precisely within the vehicle's electrical system. As a remanufactured unit, it arrives ready to install without the need for additional programming, simplifying replacement and reducing downtime.

Common Applications and Issues Addressed

• Replacement for faulty or damaged integrated control modules in Dodge Caliber, Jeep Compass, and Jeep Patriot
• Resolves electrical control failures affecting vehicle lighting and body control systems
• Addresses intermittent power issues related to control module malfunction
• Restores proper communication between vehicle electrical components
• Helps correct error codes linked to integrated power module faults

Installation Notes and Tips

Installation of the Dorman 598-729 Integrated Control Module requires careful handling of the blade-type connectors to avoid terminal damage. Since the module does not require programming, it can be installed directly after removal of the faulty unit. Ensure all connectors are fully seated and secure before testing the vehicle's electrical systems. Note that mounting hardware and wire harnesses are not included and should be reused from the original module or sourced separately.

Quality Assurance and Warranty

This remanufactured integrated control module undergoes thorough testing to meet OEM standards for fit and function. While specific warranty details are not provided, Dorman products typically come with a limited warranty covering defects in materials and workmanship. Verify warranty terms at the time of purchase to ensure coverage.
