Dorman 604-051 HVAC Blend Door Actuator - Main
OE Quality 60-Day Returns
Dorman

Dorman 604-051 HVAC Blend Door Actuator - Main

Brand Dorman 604-051
Position Main
Material Plastic
Package Contents 1 Air Door Actuator
Switch Activation Type Rotary
Terminal Gender Male
Terminal Quantity 5
Terminal Type Pin
Fits Jeep and Chrysler · 10 vehicles

OE-style replacement. Precision-engineered to match original quality and performance.

Rotary design. Provides smooth, reliable HVAC door control.

Plastic housing. Lightweight construction with a 5-pin male connector.

Cross-references Standard Ignition ADR4272, 68223051AA and ADA318 for the same application. See all 5.

$76.71Free shipping
In stock · usually ships same day before 1pm CST
Step 1 — Confirm fitment
Free return shipping if it doesn't fit when you check fitment here first.

Select your vehicle to confirm fitment
Verify this part fits before purchasing — free returns if it doesn't
Step 2 — Quantity
Order total $76.71
Free shipping to the continental U.S.
Free returns within 60 days if it doesn't fit when fitment is verified.
Not what you need? See all HVAC Blend Door Actuator options

Dorman 604-051 HVAC Blend Door Actuator

Dorman 604-051 is a rotary HVAC blend door actuator built for specific Jeep and Chrysler applications. It is precision-engineered to match the quality and performance of the original blend door actuator on the listed vehicles, helping restore proper HVAC door movement and temperature control.

  • Rotary switch activation type for HVAC blend door operation
  • 5-pin male terminal design
  • Plastic housing for direct-fit replacement use
  • Fits 2020 Jeep Cherokee, Main
  • Fits 2019 Jeep Cherokee, Main
  • Fits 2014-2018 Jeep Cherokee, Main
  • Fits 2015-2017 Chrysler 200, Main

Application Details

This HVAC blend door actuator is used in the heating and air conditioning system to move the blend door for mode selection and air distribution. It is a direct replacement for vehicles requiring the listed rotary actuator configuration, including Jeep Cherokee and Chrysler 200 models. This part number, 604-051, is also referenced for related OE and aftermarket applications, including Dorman 604-051 and Standard Ignition ADR4272.

Common HVAC Problems It Can Address

  • Incorrect air temperature from the vents
  • HVAC doors that do not respond to control changes
  • Airflow stuck on one mode setting
  • Clicking or inconsistent actuator movement behind the dash
  • Loss of proper blend door positioning in the HVAC system

Installation Notes

Verify the terminal style, pin count, and actuator type before installation. Confirm the vehicle year, make, model, and HVAC position match the listed fitment for Jeep Cherokee and Chrysler 200 applications. After installation, cycle the HVAC controls to confirm smooth blend door movement and correct mode selection.

Quality Assurance

Dorman designs this actuator as a precision replacement for the original part on the specified vehicles, with construction and performance aligned to OE requirements for the application.

Related reading

This part fits 10 vehicles
Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
YearMakeModelPositionNotes
2020JeepCherokeeMainPackaging Type: Box
2019JeepCherokeeMainFits vehicles requiring outside air, comes in a box.
2018JeepCherokeeMainHVAC Blend Door Actuator for mode selection in box packaging.
2017Chrysler200MainHVAC Blend Door Actuator for mode selection in box packaging.
2017JeepCherokeeMainHVAC Blend Door Actuator for mode selection in box packaging.
2016Chrysler200MainHVAC Blend Door Actuator for mode selection in box packaging.
2016JeepCherokeeMainHVAC Blend Door Actuator for mode selection in box packaging.
2015Chrysler200MainHVAC Blend Door Actuator for mode selection in box packaging.
2015JeepCherokeeMainHVAC Blend Door Actuator for mode selection in box packaging.
2014JeepCherokeeMainHVAC Blend Door Actuator for mode selection in box packaging.
Directly replaces or cross-references 5 part numbers
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
Standard Ignition — ADR427268223051AAADA318ADS4272APBDA0249
